The Baumer UR18.RA0.2-GP1J.9SF 11200646 is an ultrasonic sensor with a scanning range of 0 to 1000 mm and a reflector position range of 100 to 1000 mm. It features adjustable reflector ranges for both operating and limit conditions, and offers high precision with a repeat accuracy of 0.5 mm. The sensor is equipped with IO-Link technology for enhanced connectivity and configuration options, including qTeach, line-Teach, and IO-Link adjustments. It has a quick response and release time of less than 40 ms, operates at a sonic frequency of 200 kHz, and includes a helpful alignment aid with a flashing light indicator. The sensor's robust design includes a stainless steel and TR90 housing, is cylindrical threaded with a diameter of 18 mm and a length of 64 mm, and connects via an M12 5-pin connector. It operates effectively within a temperature range of -25 to +65 °C and offers high durability with IP 69 and IP 67 protection classes for the sensor and connection, respectively. The sensor is also equipped with short circuit and reverse polarity protection, ensuring reliable operation in diverse environments.
- Scanning range Sd:
- 0 1000 mm
- Reflector position Sde:
- 100 1000 mm
- Adjusting range reflector (operating range):
- ± 2,5 % Sde
- Adjusting range reflector (limit range):
- ± 5 % Sde
- Version:
- IO-Link
- Repeat accuracy:
- 0.5 mm
- Temperature drift:
- < 2 % Sde
- Power-up drift:
- Compensated after 15 min.
- Response time ton:
- < 40 ms
- Release time toff:
- < 40 ms
- Sonic frequency:
- 200 kHz
- Adjustment:
- qTeach, line-Teach, IO-Link
- Alignment aid:
- Light indicator flashing
- Light indicator:
- LED yellow
- Power on indication:
- LED green
- Alignment measuring axis:
- < 2°
- Voltage supply range +Vs:
- 12 30 VDC
- Current consumption typ.:
- 35 mA
- Output circuit:
- Push-pull
- Output current:
- 100 mA
- Voltage drop Vd:
- <3.5 VDC
- Residual ripple:
- < 10 % Vs
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Design:
- Cylindrical threaded
- Housing material:
- Stainless steel (V2A) / TR90
- Width / diameter:
- 18 mm
- Height / length:
- 64 mm
- Connection types:
- Connector M12 5 pin
- Coating active face:
- PEEK
- Operating temperature:
- -25 +65 °C
- Storage temperature:
- -40 +75 °C
- Protection class:
- IP 69
- Protection class (connection):
- IP 67
