Circuit Breakers

Circuit Breakers

  • Schneider Electric PJA36080CU43A Molded Case Circuit Breaker 600V 800A
    Add to Cart
    Quick view

    Schneider Electric PJA36080CU43A Molded Case Circuit Breaker 600V 800A

    Schneider Electric

    $26,214.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PJA36080CU43A
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Range:
    PowerPact
    Mercury Free:
    Yes
    Quantity Per Set:
    1
    Sustainable Offer Status:
    Green Premium product
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    Product Or Component Type:
    circuit breaker
    Local Signalling:
    overload 1 1 LED amber) || 1 flag green) || trip causes 4 trip indicator red)
    Height:
    12.86 in
    Pollution Degree:
    3 IEC 60947-1
    Trip Unit Technology:
    electronic, ammeter, MicroLogic 5.0 A, LSI
    Device Application:
    distribution
    Pvc Free:
    Yes
    Net Weight:
    32 lb(US)
    Warranty:
    18 months
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Product Name:
    PowerPact P
    Environmental Disclosure:
    ENVPEP2206033EN
    Breaking Capacity:
    AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Circuit Breaker Application:
    HACR rated
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Phase Connection:
    ABC
    Mounting Mode:
    I-Line bracket)
    Line Rated Current:
    800-800 A
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    Electrical Connection:
    I-Line connection, line || lugs, load
    Wire Stripping Length:
    25 mm
    Mounting Height:
    9 in
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Ambient Air Temperature For Storage:
    -50-85 °C
    Eu Rohs Directive:
    Compliant with Exemptions
    Network Frequency:
    50/60 Hz
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Quality Labels:
    CE
    Ip Degree Of Protection:
    front cover IP40
    Breaking Capacity Code:
    J
    Circularity Profile:
    ENVEOLI2206033EN
    Mounting Support:
    bracket
    Poles Description:
    3P
    Terminal Identifier:
    AL800M23K
    Width:
    8.27 in
    Product Certifications:
    UL || CSA || NOM
    Ambient Air Temperature For Operation:
    -2-70 °C
    Control Type:
    toggle
    Depth:
    8.05 in
    [Ics] Rated Service Breaking Capacity:
    35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Continuous Current Rating:
    1
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Rohs Exemption Information:
    Yes
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Trip Unit Name:
    MicroLogic 5.0 A
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $26,214.00
    Add to Cart Quick view
  • Schneider Electric PJA36060CU43A Molded Case Circuit Breaker 600V 600A
    Add to Cart
    Quick view

    Schneider Electric PJA36060CU43A Molded Case Circuit Breaker 600V 600A

    Schneider Electric

    $26,214.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PJA36060CU43A
    Mounting Mode:
    I-Line bracket)
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Trip Unit Name:
    MicroLogic 5.0 A
    Mounting Support:
    bracket
    Control Type:
    toggle
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Electrical Connection:
    I-Line connection, line || lugs, load
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Terminal Identifier:
    AL800M23K
    Local Signalling:
    1 trip indicator green)
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Height:
    12.86 in
    Ip Degree Of Protection:
    front cover IP40
    Quality Labels:
    CE
    Product Certifications:
    UL || CSA || NOM
    Width:
    8.27 in
    Trip Unit Technology:
    electronic, ammeter, MicroLogic 5.0 A, LSI
    Line Rated Current:
    600-600 A
    Eu Rohs Directive:
    Compliant with Exemptions
    Rohs Exemption Information:
    Yes
    Breaking Capacity:
    AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Device Application:
    distribution
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    Breaking Capacity Code:
    J
    Circuit Breaker Application:
    HACR rated
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Mercury Free:
    Yes
    Ambient Air Temperature For Storage:
    -50-85 °C
    Mounting Height:
    9 in
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Net Weight:
    32 lb(US)
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Ambient Air Temperature For Operation:
    -2-70 °C
    Continuous Current Rating:
    1
    Poles Description:
    3P
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    [Ics] Rated Service Breaking Capacity:
    35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Depth:
    8.05 in
    Warranty:
    18 months
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Network Frequency:
    50/60 Hz
    Quantity Per Set:
    1
    Phase Connection:
    ABC
    Wire Stripping Length:
    25 mm
    Product Name:
    PowerPact P
    Pvc Free:
    Yes
    Sustainable Offer Status:
    Green Premium product
    Range:
    PowerPact
    Product Or Component Type:
    circuit breaker
    Environmental Disclosure:
    ENVPEP2206033EN
    Circularity Profile:
    ENVEOLI2206033EN
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Pollution Degree:
    3 IEC 60947-1
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $26,214.00
    Add to Cart Quick view
  • Schneider Electric PGL36080CU33A Molded Case Circuit Breaker 600V 800A
    Add to Cart
    Quick view

    Schneider Electric PGL36080CU33A Molded Case Circuit Breaker 600V 800A

    Schneider Electric

    $21,812.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PGL36080CU33A
    Circuit Breaker Application:
    HACR rated
    Warranty:
    18 months
    Product Certifications:
    UL || CSA || NOM
    Ambient Air Temperature For Operation:
    -2-70 °C
    Pollution Degree:
    3 IEC 60947-1
    Pvc Free:
    Yes
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Line Rated Current:
    800-800 A
    Product Name:
    PowerPact P
    Device Application:
    distribution
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Quality Labels:
    CE
    Continuous Current Rating:
    1
    Trip Unit Technology:
    electronic, standard, MicroLogic 5.0, LSI
    Height:
    12.86 in
    Poles Description:
    3P
    Breaking Capacity Code:
    G
    Circularity Profile:
    ENVEOLI2206033EN
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Network Frequency:
    50/60 Hz
    Electrical Connection:
    lugs, load || lugs, line
    Environmental Disclosure:
    ENVPEP2206033EN
    Wire Stripping Length:
    25 mm
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Ip Degree Of Protection:
    front cover IP40
    [Ics] Rated Service Breaking Capacity:
    25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Depth:
    8.05 in
    Net Weight:
    32 lb(US)
    Rohs Exemption Information:
    Yes
    Terminal Identifier:
    AL800M23K
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Mercury Free:
    Yes
    Range:
    PowerPact
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Product Or Component Type:
    circuit breaker
    Sustainable Offer Status:
    Green Premium product
    Control Type:
    toggle
    Ambient Air Temperature For Storage:
    -50-85 °C
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Trip Unit Name:
    MicroLogic 5.0
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Eu Rohs Directive:
    Compliant with Exemptions
    Quantity Per Set:
    1
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Local Signalling:
    overload 1 1 LED amber) || 1 trip indicator green)
    Width:
    8.27 in
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $21,812.00
    Add to Cart Quick view
  • Schneider Electric PGL36060CU33A Molded Case Circuit Breaker 600V 600A
    Add to Cart
    Quick view

    Schneider Electric PGL36060CU33A Molded Case Circuit Breaker 600V 600A

    Schneider Electric

    $21,812.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PGL36060CU33A
    Ambient Air Temperature For Operation:
    -2-70 °C
    Pollution Degree:
    3 IEC 60947-1
    Network Frequency:
    50/60 Hz
    Circularity Profile:
    ENVEOLI2206033EN
    Height:
    12.86 in
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    Eu Rohs Directive:
    Compliant with Exemptions
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Range:
    PowerPact
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Terminal Identifier:
    AL800M23K
    Poles Description:
    3P
    Quantity Per Set:
    1
    Device Application:
    distribution
    Quality Labels:
    CE
    Product Or Component Type:
    circuit breaker
    Control Type:
    toggle
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    Electrical Connection:
    lugs, load || lugs, line
    Trip Unit Name:
    MicroLogic 5.0
    Wire Stripping Length:
    25 mm
    Environmental Disclosure:
    ENVPEP2206033EN
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Mercury Free:
    Yes
    Rohs Exemption Information:
    Yes
    Trip Unit Technology:
    electronic, standard, MicroLogic 5.0, LSI
    Warranty:
    18 months
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Sustainable Offer Status:
    Green Premium product
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Line Rated Current:
    600-600 A
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Pvc Free:
    Yes
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Breaking Capacity Code:
    G
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    [Ics] Rated Service Breaking Capacity:
    25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Net Weight:
    32 lb(US)
    Depth:
    8.05 in
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Continuous Current Rating:
    1
    Width:
    8.27 in
    Ambient Air Temperature For Storage:
    -50-85 °C
    Local Signalling:
    overload 1 1 LED amber) || 1 trip indicator green)
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Product Certifications:
    UL || CSA || NOM
    Circuit Breaker Application:
    HACR rated
    Ip Degree Of Protection:
    front cover IP40
    Product Name:
    PowerPact P
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $21,812.00
    Add to Cart Quick view
  • Schneider Electric MJL36450 Molded Case Circuit Breaker 600V 450A
    Add to Cart
    Quick view

    Schneider Electric MJL36450 Molded Case Circuit Breaker 600V 450A

    Schneider Electric

    $9,456.00
    PowerPacT M-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT M-Frame circuit breakers have either a fixed long time electronic trip unit or an adjustable amperage version...
    SKU:
    MJL36450
    Quality Labels:
    CE
    Color:
    Black
    Trip Unit Name:
    ET 1.0
    Product Certifications:
    UL || CSA || NOM
    Pvc Free:
    Yes
    Sustainable Offer Status:
    Green Premium product
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Network Frequency:
    50/60 Hz
    Long Time Pick-Up Adjustment Range:
    300...800 A
    Circuit Breaker Application:
    HACR rated
    Device Application:
    distribution
    Quantity Per Set:
    1
    Eu Rohs Directive:
    Compliant with Exemptions
    Product Or Component Type:
    circuit breaker
    Width:
    8.27 in
    Breaking Capacity Code:
    J
    Mercury Free:
    Yes
    Ip Degree Of Protection:
    IP40
    Control Type:
    operating handle
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
    Pollution Degree:
    3 IEC 60947-1
    Continuous Current Rating:
    0.8
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Local Signalling:
    1 trip indicator green)
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...3 x 500 kcmil)
    Rohs Exemption Information:
    Yes
    Range:
    PowerPact
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Wire Stripping Length:
    25 mm
    Environmental Disclosure:
    ENVPEP2206030EN
    Breaking Capacity:
    AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Line Rated Current:
    450-450 A
    Mounting Mode:
    unit mount lug)
    Mounting Support:
    lug
    Awg Gauge:
    3 x AWG 3/0...3 x 500 kcmil aluminium/copper
    Terminal Identifier:
    AL800M23K
    Suitability For Isolation:
    yes IEC 60947-2
    Ambient Air Temperature For Operation:
    -25-70 °C
    Product Name:
    PowerPact M
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Trip Unit Technology:
    electronic, basic, ET 1.0,
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    [Ics] Rated Service Breaking Capacity:
    35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Height:
    12.86 in
    Warranty:
    18 months
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Depth:
    8.05 in
    Electrical Connection:
    lugs, load || lugs, line
    Net Weight:
    29 lb(US)
    Circularity Profile:
    ENVEOLI2206030EN
    Magnetic Tripping Current:
    900-4500 A
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Ambient Air Temperature For Storage:
    -50-85 °C
    Utilisation Category:
    category A
    Poles Description:
    3P
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $9,456.00
    Add to Cart Quick view
  • Schneider Electric RGF36120 Molded Case Circuit Breaker 600V 1200A
    Add to Cart
    Quick view

    Schneider Electric RGF36120 Molded Case Circuit Breaker 600V 1200A

    Schneider Electric

    $22,373.00
    PowerPacT R-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT R-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    RGF36120
    Pollution Degree:
    3 IEC 60947-1
    Quantity Per Set:
    1
    Ambient Air Temperature For Storage:
    -50-85 °C
    Utilisation Category:
    category A
    Control Type:
    operating handle
    Warranty:
    18 months
    Tightening Torque:
    68-68 N.m 50-400 mm² (AWG 1/0...750 kcmil) || 68-68 N.m 50-150 mm² (2 x AWG 1/0...2 x 300 kcmil)
    Network Frequency:
    50/60 Hz
    Wire Stripping Length:
    35 mm
    Line Rated Current:
    1200-1200 A
    Depth:
    14.49 in
    Mounting Mode:
    unit mount busbar)
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Height:
    16.24 in
    Electrical Connection:
    busbar connection, line || busbar connection, load
    Poles Description:
    3P
    [Ics] Rated Service Breaking Capacity:
    25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Ambient Air Temperature For Operation:
    -25-70 °C
    Mercury Free:
    Yes
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Eu Rohs Directive:
    Compliant with Exemptions
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Quality Labels:
    CE
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Continuous Current Rating:
    0.8
    Device Application:
    distribution
    Product Name:
    PowerPact R
    Standards:
    UL || CSA || NEMA || NMX J-266 || IEC 60947-2
    Local Signalling:
    trip indicator
    Net Weight:
    52 lb(US)
    Circuit Breaker Application:
    HACR rated
    Halogen Content Performance:
    Halogen free plastic parts product
    Terminal Identifier:
    AL2500RK
    Sustainable Offer Status:
    Green Premium product
    Trip Unit Technology:
    electronic, basic, ET 1.0I, I
    Environmental Disclosure:
    ENVPEP2206034EN
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Magnetic Tripping Current:
    1800-14400 A
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
    Mounting Support:
    busbar
    Product Certifications:
    UL || CSA || NOM
    Circularity Profile:
    ENVEOLI2206034EN
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Suitability For Isolation:
    yes IEC 60947-2
    Breaking Capacity Code:
    G
    Trip Unit Name:
    ET 1.0I
    Range:
    PowerPact
    Width:
    16.53 in
    Pvc Free:
    Yes
    Ip Degree Of Protection:
    IP40
    Rohs Exemption Information:
    Yes
    Awg Gauge:
    AWG 3/0...750 kcmil aluminium/copper
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Product Or Component Type:
    circuit breaker
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $22,373.00
    Add to Cart Quick view
  • Schneider Electric RKF36160U64AE1 Molded Case Circuit Breaker 600V 1600A
    Add to Cart
    Quick view

    Schneider Electric RKF36160U64AE1 Molded Case Circuit Breaker 600V 1600A

    Schneider Electric

    $32,180.00
    PowerPacT R-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT R-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    RKF36160U64AE1
    Ambient Air Temperature For Operation:
    -25-70 °C
    Range:
    PowerPact
    Ambient Air Temperature For Storage:
    -50-85 °C
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
    Network Frequency:
    50/60 Hz
    Awg Gauge:
    AWG 3/0...750 kcmil aluminium/copper
    Quantity Per Set:
    1
    Quality Labels:
    CE
    Width:
    16.53 in
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Poles Description:
    3P
    Trip Unit Technology:
    electronic, power, MicroLogic 6.0 P, LSIG
    Rohs Exemption Information:
    Yes
    Standards:
    UL || CSA || NEMA || NMX J-266 || IEC 60947-2
    Environmental Disclosure:
    ENVPEP1407013EN
    Wire Stripping Length:
    35 mm
    Product Or Component Type:
    circuit breaker
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Trip Unit Name:
    MicroLogic 6.0 P
    Terminal Identifier:
    AL2500RK
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Continuous Current Rating:
    0.8
    Utilisation Category:
    category A
    Ip Degree Of Protection:
    IP40
    Product Name:
    PowerPact R
    Line Rated Current:
    1600-1600 A
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 65 kA 600 V AC 50/60 Hz UL 489 || Icu 85 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 70 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Halogen Content Performance:
    Halogen free plastic parts product
    Eu Rohs Directive:
    Compliant
    Mounting Mode:
    unit mount busbar)
    Sustainable Offer Status:
    Green Premium product
    Communication Interface:
    Modbus
    Tightening Torque:
    68-68 N.m 50-400 mm² (AWG 1/0...750 kcmil) || 68-68 N.m 50-150 mm² (2 x AWG 1/0...2 x 300 kcmil)
    Depth:
    14.49 in
    Circuit Breaker Application:
    HACR rated
    Mounting Support:
    busbar
    Breaking Capacity Code:
    K
    [Ics] Rated Service Breaking Capacity:
    65 kA 240 V AC 50/60 Hz IEC 60947-2 || 55 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Suitability For Isolation:
    yes IEC 60947-2
    Mercury Free:
    Yes
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Product Certifications:
    UL || CSA || NOM
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Device Application:
    distribution
    Electrical Connection:
    busbar connection, line || busbar connection, load
    Local Signalling:
    alarm 1 LED yellow)long-time pick up) || 1 LED red)long-time pick up) || trip causes 1 LED red) || 1 LED red)digital ammeter) || ground indicator 1 LED red) || phase-loading LED green)load balancing)
    Net Weight:
    52 lb(US)
    Height:
    16.24 in
    Pollution Degree:
    3 IEC 60947-1
    Warranty:
    18 months
    Circularity Profile:
    ENVEOLI1407013EN
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Control Type:
    operating handle
    Pvc Free:
    Yes
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $32,180.00
    Add to Cart Quick view
  • Schneider Electric RGA36120CU31A Molded Case Circuit Breaker 600V 1200A
    Add to Cart
    Quick view

    Schneider Electric RGA36120CU31A Molded Case Circuit Breaker 600V 1200A

    Schneider Electric

    $33,945.00
    PowerPacT R-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT R-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    RGA36120CU31A
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Product Name:
    PowerPact R
    Mounting Mode:
    I-Line bracket)
    Pollution Degree:
    3 IEC 60947-1
    Trip Unit Technology:
    electronic, standard, MicroLogic 3.0, LI
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Ip Degree Of Protection:
    IP40
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Pvc Free:
    Yes
    Awg Gauge:
    4 x AWG 3/0…600 kcmil aluminium/copper || 4 x AWG 3/0...500 kcmil copper
    Control Type:
    operating handle
    Device Application:
    distribution
    Utilisation Category:
    category A
    Breaking Capacity Code:
    G
    Wire Stripping Length:
    30 mm
    Ambient Air Temperature For Storage:
    -50-85 °C
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Trip Unit Name:
    MicroLogic 3.0
    Local Signalling:
    alarm 1 LED yellow)long-time pick up)
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Quantity Per Set:
    1
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 voltage release MN or MX plug-in)
    Range:
    PowerPact
    Width:
    14.96 in
    Electrical Connection:
    I-Line connection, line || lugs, load
    Network Frequency:
    50/60 Hz
    Environmental Disclosure:
    ENVPEP1407013EN
    Terminal Identifier:
    AL1200R53K
    Line Rated Current:
    1200-1200 A
    Warranty:
    18 months
    Depth:
    13.78 in
    Circularity Profile:
    ENVEOLI1407013EN
    Mercury Free:
    Yes
    Quality Labels:
    CE
    Sustainable Offer Status:
    Green Premium product
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Tightening Torque:
    28-28 N.m 95-240 mm² (4 x AWG 3/0…600 kcmil)
    Standards:
    UL || CSA || NEMA || NMX J-266 || IEC 60947-2
    Halogen Content Performance:
    Halogen free plastic parts product
    Height:
    13.38 in
    Rohs Exemption Information:
    Yes
    Eu Rohs Directive:
    Compliant
    Poles Description:
    3P
    Net Weight:
    52 lb(US)
    Product Certifications:
    UL || CSA || NOM
    Continuous Current Rating:
    1
    [Ics] Rated Service Breaking Capacity:
    25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Ambient Air Temperature For Operation:
    -25-70 °C
    Mounting Support:
    bracket
    Product Or Component Type:
    circuit breaker
    Suitability For Isolation:
    yes IEC 60947-2
    Circuit Breaker Application:
    HACR rated
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $33,945.00
    Add to Cart Quick view
  • Schneider Electric PLM34120CU44A Molded Case Circuit Breaker 480V 1200A
    Add to Cart
    Quick view

    Schneider Electric PLM34120CU44A Molded Case Circuit Breaker 480V 1200A

    Schneider Electric

    $38,270.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PLM34120CU44A
    Poles Description:
    3P
    Warranty:
    18 months
    Eu Rohs Directive:
    Compliant with Exemptions
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Quality Labels:
    CE
    Ip Degree Of Protection:
    front cover IP40
    Circuit Breaker Application:
    HACR rated
    Mounting Support:
    lug
    Ambient Air Temperature For Operation:
    -2-70 °C
    Trip Unit Name:
    MicroLogic 6.0 A
    Tightening Torque:
    50-50 N.m 95-240 mm² (4 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    Environmental Disclosure:
    ENVPEP2206033EN
    Device Application:
    distribution
    Quantity Per Set:
    1
    Height:
    16.16 in
    Network Frequency:
    50/60 Hz
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Mounting Mode:
    unit mount lug)
    Depth:
    8.05 in
    Rohs Exemption Information:
    Yes
    Circularity Profile:
    ENVEOLI2206033EN
    Net Weight:
    32 lb(US)
    Control Type:
    toggle
    Electrical Connection:
    lugs, line || terminal nut, load
    Width:
    8.27 in
    Local Signalling:
    overload 1 trip indicator green) || 1 trip indicator green) || trip causes 1 trip indicator green)
    Pollution Degree:
    3 IEC 60947-1
    Mercury Free:
    Yes
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Sustainable Offer Status:
    Green Premium product
    Breaking Capacity Code:
    L
    Wire Stripping Length:
    30 mm
    Continuous Current Rating:
    1
    Breaking Capacity:
    AIR 125 kA 240 V AC 50/60 Hz UL 489 || AIR 100 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 125 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 85 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Product Name:
    PowerPact P
    Trip Unit Technology:
    electronic, ammeter, MicroLogic 6.0 A, LSIG
    Awg Gauge:
    4 x AWG 3/0...500 kcmil aluminium/copper
    Ambient Air Temperature For Storage:
    -50-85 °C
    [Ue] Rated Operational Voltage:
    480 V AC 50/60 Hz UL 489
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Pvc Free:
    Yes
    Product Certifications:
    UL || CSA || NOM
    Range:
    PowerPact
    Product Or Component Type:
    circuit breaker
    [Ics] Rated Service Breaking Capacity:
    65 kA 240 V AC 50/60 Hz IEC 60947-2 || 45 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Line Rated Current:
    1200-1200 A
    Terminal Identifier:
    AL1200P25K
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $38,270.00
    Add to Cart Quick view
  • Schneider Electric PGA261202 Molded Case Circuit Breaker 600V 1200A
    Add to Cart
    Quick view

    Schneider Electric PGA261202 Molded Case Circuit Breaker 600V 1200A

    Schneider Electric

    $27,481.50
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PGA261202
    Height:
    16.16 in
    Network Frequency:
    50/60 Hz
    Tightening Torque:
    50-50 N.m 95-240 mm² (4 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Trip Unit Name:
    ET 1.0I
    Pollution Degree:
    3 IEC 60947-1
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Sustainable Offer Status:
    Green Premium product
    Environmental Disclosure:
    ENVPEP1407012EN
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Mounting Support:
    bracket
    Quality Labels:
    CE
    Product Certifications:
    UL || CSA || NOM
    Local Signalling:
    1 trip indicator green)
    Mounting Mode:
    I-Line bracket)
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Ip Degree Of Protection:
    front cover IP40
    Quantity Per Set:
    1
    Continuous Current Rating:
    0.8
    Wire Stripping Length:
    30 mm
    Net Weight:
    32 lb(US)
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Warranty:
    18 months
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    [Ics] Rated Service Breaking Capacity:
    25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Line Rated Current:
    1200-1200 A
    Trip Unit Technology:
    electronic, basic, ET 1.0I, I
    Awg Gauge:
    4 x AWG 3/0...500 kcmil aluminium/copper
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Eu Rohs Directive:
    Compliant
    Circuit Breaker Application:
    HACR rated
    Range:
    PowerPact
    Depth:
    8.05 in
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Mounting Height:
    9 in
    Electrical Connection:
    I-Line connection, line || lugs, load
    Mercury Free:
    Yes
    Product Name:
    PowerPact P
    Terminal Identifier:
    AL1200P25K
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Phase Connection:
    AC
    Circularity Profile:
    ENVEOLI1407012EN
    Pvc Free:
    Yes
    Rohs Exemption Information:
    Yes
    Long Time Pick-Up Adjustment Range:
    1 In
    Device Application:
    distribution
    Width:
    8.27 in
    Poles Description:
    2P
    Ambient Air Temperature For Storage:
    -50-85 °C
    Product Or Component Type:
    circuit breaker
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Control Type:
    toggle
    Breaking Capacity Code:
    G
    Ambient Air Temperature For Operation:
    -2-70 °C
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $27,481.50
    Add to Cart Quick view
  • Schneider Electric PJA36025U31A Molded Case Circuit Breaker 600V 250A
    Add to Cart
    Quick view

    Schneider Electric PJA36025U31A Molded Case Circuit Breaker 600V 250A

    Schneider Electric

    $16,268.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PJA36025U31A
    Mounting Support:
    bracket
    Network Frequency:
    50/60 Hz
    Breaking Capacity:
    AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Mounting Height:
    9 in
    Local Signalling:
    overload 1 trip indicator green) || 1 trip indicator green)
    Ambient Air Temperature For Operation:
    -2-70 °C
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Circularity Profile:
    ENVEOLI2206033EN
    Pollution Degree:
    3 IEC 60947-1
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    Continuous Current Rating:
    0.8
    Control Type:
    toggle
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Mercury Free:
    Yes
    Terminal Identifier:
    AL800M23K
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Device Application:
    distribution
    Range:
    PowerPact
    Eu Rohs Directive:
    Compliant with Exemptions
    Electrical Connection:
    I-Line connection, line || lugs, load
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Net Weight:
    32 lb(US)
    Phase Connection:
    ABC
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Sustainable Offer Status:
    Green Premium product
    Trip Unit Name:
    MicroLogic 3.0
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Warranty:
    18 months
    Product Name:
    PowerPact P
    Height:
    12.86 in
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Trip Unit Technology:
    electronic, standard, MicroLogic 3.0, LI
    Product Certifications:
    UL || CSA || NOM
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Pvc Free:
    Yes
    Depth:
    8.05 in
    Mounting Mode:
    I-Line bracket)
    Quantity Per Set:
    1
    [Ics] Rated Service Breaking Capacity:
    35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Wire Stripping Length:
    25 mm
    Quality Labels:
    CE
    Product Or Component Type:
    circuit breaker
    Poles Description:
    3P
    Breaking Capacity Code:
    J
    Environmental Disclosure:
    ENVPEP2206033EN
    Rohs Exemption Information:
    Yes
    Ambient Air Temperature For Storage:
    -50-85 °C
    Ip Degree Of Protection:
    front cover IP40
    Width:
    8.27 in
    Circuit Breaker Application:
    HACR rated
    Line Rated Current:
    250-250 A
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $16,268.00
    Add to Cart Quick view
  • Schneider Electric PJA36060U44A Molded Case Circuit Breaker 600V 600A
    Add to Cart
    Quick view

    Schneider Electric PJA36060U44A Molded Case Circuit Breaker 600V 600A

    Schneider Electric

    $20,486.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PJA36060U44A
    Phase Connection:
    ABC
    Trip Unit Name:
    MicroLogic 6.0 A
    Pollution Degree:
    3 IEC 60947-1
    Mercury Free:
    Yes
    Rohs Exemption Information:
    Yes
    Network Frequency:
    50/60 Hz
    Environmental Disclosure:
    ENVPEP2206033EN
    Mounting Support:
    bracket
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Poles Description:
    3P
    Electrical Connection:
    I-Line connection, line || lugs, load
    Continuous Current Rating:
    0.8
    Product Certifications:
    UL || CSA || NOM
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Control Type:
    toggle
    Ip Degree Of Protection:
    front cover IP40
    [Ics] Rated Service Breaking Capacity:
    35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Breaking Capacity Code:
    J
    Pvc Free:
    Yes
    Quantity Per Set:
    1
    Mounting Height:
    9 in
    Warranty:
    18 months
    Product Or Component Type:
    circuit breaker
    Circuit Breaker Application:
    HACR rated
    Width:
    8.27 in
    Device Application:
    distribution
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    Eu Rohs Directive:
    Compliant with Exemptions
    Circularity Profile:
    ENVEOLI2206033EN
    Line Rated Current:
    600-600 A
    Depth:
    8.05 in
    Quality Labels:
    CE
    Product Name:
    PowerPact P
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Terminal Identifier:
    AL800M23K
    Sustainable Offer Status:
    Green Premium product
    Mounting Mode:
    I-Line bracket)
    Local Signalling:
    1 trip indicator green)
    Trip Unit Technology:
    electronic, ammeter, MicroLogic 6.0 A, LSIG
    Height:
    12.86 in
    Net Weight:
    32 lb(US)
    Breaking Capacity:
    AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    Wire Stripping Length:
    25 mm
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Range:
    PowerPact
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Ambient Air Temperature For Operation:
    -2-70 °C
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Ambient Air Temperature For Storage:
    -50-85 °C
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $20,486.00
    Add to Cart Quick view
  • Schneider Electric PJA36060U33A Molded Case Circuit Breaker 600V 600A
    Add to Cart
    Quick view

    Schneider Electric PJA36060U33A Molded Case Circuit Breaker 600V 600A

    Schneider Electric

    $16,608.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PJA36060U33A
    Mounting Height:
    9 in
    Trip Unit Technology:
    electronic, standard, MicroLogic 5.0, LSI
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    Product Or Component Type:
    circuit breaker
    Mercury Free:
    Yes
    Sustainable Offer Status:
    Green Premium product
    Quality Labels:
    CE
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Continuous Current Rating:
    0.8
    Depth:
    8.05 in
    Height:
    12.86 in
    Environmental Disclosure:
    ENVPEP2206033EN
    Electrical Connection:
    I-Line connection, line || lugs, load
    Control Type:
    toggle
    Trip Unit Name:
    MicroLogic 5.0
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Breaking Capacity Code:
    J
    Poles Description:
    3P
    Mounting Support:
    bracket
    Line Rated Current:
    600-600 A
    [Ics] Rated Service Breaking Capacity:
    35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Network Frequency:
    50/60 Hz
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Product Certifications:
    UL || CSA || NOM
    Warranty:
    18 months
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Ip Degree Of Protection:
    front cover IP40
    Rohs Exemption Information:
    Yes
    Phase Connection:
    ABC
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Terminal Identifier:
    AL800M23K
    Range:
    PowerPact
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    Device Application:
    distribution
    Quantity Per Set:
    1
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Wire Stripping Length:
    25 mm
    Ambient Air Temperature For Operation:
    -2-70 °C
    Breaking Capacity:
    AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Local Signalling:
    1 trip indicator green)
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Product Name:
    PowerPact P
    Pollution Degree:
    3 IEC 60947-1
    Net Weight:
    32 lb(US)
    Circularity Profile:
    ENVEOLI2206033EN
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Width:
    8.27 in
    Mounting Mode:
    I-Line bracket)
    Eu Rohs Directive:
    Compliant with Exemptions
    Ambient Air Temperature For Storage:
    -50-85 °C
    Pvc Free:
    Yes
    Circuit Breaker Application:
    HACR rated
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $16,608.00
    Add to Cart Quick view
  • Schneider Electric PJL36120 Molded Case Circuit Breaker 600V 1200A
    Add to Cart
    Quick view

    Schneider Electric PJL36120 Molded Case Circuit Breaker 600V 1200A

    Schneider Electric

    $20,250.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PJL36120
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Suitability For Isolation:
    yes IEC 60947-2
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Wire Stripping Length:
    30 mm
    Depth:
    8.05 in
    Width:
    8.27 in
    Eu Rohs Directive:
    Compliant with Exemptions
    Ambient Air Temperature For Operation:
    -2-70 °C
    Circuit Breaker Application:
    HACR rated
    Ip Degree Of Protection:
    front cover IP40
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Local Signalling:
    1 trip indicator green)
    Range:
    PowerPact
    Environmental Disclosure:
    ENVPEP2206033EN
    Ambient Air Temperature For Storage:
    -50-85 °C
    Tightening Torque:
    50-50 N.m 95-240 mm² (4 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Poles Description:
    3P
    Breaking Capacity:
    AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Device Application:
    distribution
    Long Time Pick-Up Adjustment Range:
    1 In
    Net Weight:
    32 lb(US)
    Height:
    16.16 in
    Warranty:
    18 months
    Quantity Per Set:
    1
    Electrical Connection:
    lugs, line || lugs, load
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Circularity Profile:
    ENVEOLI2206033EN
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Utilisation Category:
    category A
    Product Or Component Type:
    circuit breaker
    [Ics] Rated Service Breaking Capacity:
    35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Line Rated Current:
    1200-1200 A
    Quality Labels:
    CE
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Network Frequency:
    50/60 Hz
    Product Name:
    PowerPact P
    Pollution Degree:
    3 IEC 60947-1
    Terminal Identifier:
    AL1200P25K
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Mercury Free:
    Yes
    Mounting Support:
    lug
    Mounting Mode:
    unit mount lug)
    Sustainable Offer Status:
    Green Premium product
    Trip Unit Technology:
    electronic, basic, ET 1.0I, I
    Control Type:
    toggle
    Rohs Exemption Information:
    Yes
    Product Certifications:
    UL || CSA || NOM
    Trip Unit Name:
    ET 1.0I
    Awg Gauge:
    4 x AWG 3/0...500 kcmil aluminium/copper
    Continuous Current Rating:
    0.8
    Breaking Capacity Code:
    J
    Pvc Free:
    Yes
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $20,250.00
    Add to Cart Quick view
  • Schneider Electric PGL36120U44A Molded Case Circuit Breaker 600V 1200A
    Add to Cart
    Quick view

    Schneider Electric PGL36120U44A Molded Case Circuit Breaker 600V 1200A

    Schneider Electric

    $24,054.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PGL36120U44A
    Trip Unit Technology:
    electronic, ammeter, MicroLogic 6.0 A, LSIG
    Ip Degree Of Protection:
    front cover IP40
    Width:
    8.27 in
    Quantity Per Set:
    1
    Rohs Exemption Information:
    Yes
    Poles Description:
    3P
    Pollution Degree:
    3 IEC 60947-1
    Warranty:
    18 months
    Environmental Disclosure:
    ENVPEP2206033EN
    Circularity Profile:
    ENVEOLI2206033EN
    Ambient Air Temperature For Storage:
    -50-85 °C
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Range:
    PowerPact
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Ambient Air Temperature For Operation:
    -2-70 °C
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Terminal Identifier:
    AL1200P25K
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Tightening Torque:
    50-50 N.m 95-240 mm² (4 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Line Rated Current:
    1200-1200 A
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Height:
    16.16 in
    Mercury Free:
    Yes
    Pvc Free:
    Yes
    Electrical Connection:
    lugs, load || lugs, line
    Product Name:
    PowerPact P
    Product Certifications:
    UL || CSA || NOM
    Device Application:
    distribution
    [Ics] Rated Service Breaking Capacity:
    25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Net Weight:
    32 lb(US)
    Product Or Component Type:
    circuit breaker
    Wire Stripping Length:
    30 mm
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Breaking Capacity Code:
    G
    Local Signalling:
    1 trip indicator green)
    Sustainable Offer Status:
    Green Premium product
    Awg Gauge:
    4 x AWG 3/0...500 kcmil aluminium/copper
    Continuous Current Rating:
    0.8
    Network Frequency:
    50/60 Hz
    Circuit Breaker Application:
    HACR rated
    Depth:
    8.05 in
    Quality Labels:
    CE
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Control Type:
    toggle
    Eu Rohs Directive:
    Compliant with Exemptions
    Trip Unit Name:
    MicroLogic 6.0 A
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $24,054.00
    Add to Cart Quick view
  • Schneider Electric PGA36025U31A Molded Case Circuit Breaker 600V 250A
    Add to Cart
    Quick view

    Schneider Electric PGA36025U31A Molded Case Circuit Breaker 600V 250A

    Schneider Electric

    $15,390.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PGA36025U31A
    Circularity Profile:
    ENVEOLI1407012EN
    Ambient Air Temperature For Operation:
    -2-70 °C
    Sustainable Offer Status:
    Green Premium product
    Circuit Breaker Application:
    HACR rated
    Wire Stripping Length:
    25 mm
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Phase Connection:
    ABC
    Depth:
    8.05 in
    Local Signalling:
    1 trip indicator green)
    Eu Rohs Directive:
    Compliant
    Mounting Support:
    bracket
    Range:
    PowerPact
    Trip Unit Technology:
    electronic, standard, MicroLogic 3.0, LI
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    Network Frequency:
    50/60 Hz
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Rohs Exemption Information:
    Yes
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Product Name:
    PowerPact P
    Pollution Degree:
    3 IEC 60947-1
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Electrical Connection:
    I-Line connection, line || lugs, load
    Pvc Free:
    Yes
    Quantity Per Set:
    1
    Quality Labels:
    CE
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Control Type:
    toggle
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Environmental Disclosure:
    ENVPEP1407012EN
    Product Certifications:
    UL || CSA || NOM
    Ip Degree Of Protection:
    front cover IP40
    Mercury Free:
    Yes
    [Ics] Rated Service Breaking Capacity:
    25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Terminal Identifier:
    AL800M23K
    Warranty:
    18 months
    Poles Description:
    3P
    Breaking Capacity Code:
    G
    Mounting Height:
    9 in
    Mounting Mode:
    I-Line bracket)
    Trip Unit Name:
    MicroLogic 3.0
    Net Weight:
    32 lb(US)
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Ambient Air Temperature For Storage:
    -50-85 °C
    Continuous Current Rating:
    0.8
    Width:
    8.27 in
    Height:
    12.86 in
    Product Or Component Type:
    circuit breaker
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Device Application:
    distribution
    Line Rated Current:
    250-250 A
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $15,390.00
    Add to Cart Quick view
  • Schneider Electric JJL36250U33X Molded Case Circuit Breaker 600V 250A
    Add to Cart
    Quick view

    Schneider Electric JJL36250U33X Molded Case Circuit Breaker 600V 250A

    Schneider Electric

    $5,923.00
    PowerPacT J-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT J-Frame circuit breakers are available with either thermal magnetic or MicroLogic electronic trip protection units...
    SKU:
    JJL36250U33X
    Protection Type:
    overload protection || short-circuit protection
    Ip Degree Of Protection:
    front cover IP40
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Long Time Pick-Up Adjustment Range:
    0.25...1 x In
    Wire Stripping Length:
    25 mm
    Suitability For Isolation:
    yes IEC 60947-2
    Net Weight:
    2.4 kg
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz IEC 60947-3
    Ambient Air Temperature For Storage:
    -50-85 °C
    Rohs Exemption Information:
    Yes
    Poles Description:
    3P
    Sustainable Offer Status:
    Green Premium product
    Mounting Mode:
    unit mount lug)
    Electrical Connection:
    lugs, line || lugs, load
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Product Or Component Type:
    circuit breaker
    Pvc Free:
    Yes
    Eu Rohs Directive:
    Compliant with Exemptions
    Continuous Current Rating:
    0.8
    Line Rated Current:
    250-250 A
    Width:
    104 mm
    Trip Unit Technology:
    electronic, standard, MicroLogic 3.2 S, LSI
    Utilisation Category:
    category A
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Environmental Disclosure:
    ENVPEP2206032EN
    Quality Labels:
    CE
    Ambient Air Temperature For Operation:
    -2-70 °C
    Mercury Free:
    Yes
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Depth:
    86 mm
    Tightening Torque:
    25-25 N.m 95-185 mm² (AWG 3/0...350 kcmil)
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Circularity Profile:
    ENVEOLI2206032EN
    Breaking Capacity:
    100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
    Product Certifications:
    UL || CSA || NOM
    Awg Gauge:
    AWG 3/0...350 kcmil aluminium/copper terminals
    Trip Unit Name:
    MicroLogic 3.2 S
    Pollution Degree:
    3
    Control Type:
    toggle
    Breaking Capacity Code:
    J
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Height:
    191 mm
    Warranty:
    18 months
    Communication Interface:
    Modbus
    Terminal Identifier:
    AL250JD
    Local Signalling:
    ready 1 LED green) || alarm 1 LED 90 % Ir orange) || alarm 1 LED 105 % Ir red) || switched off (OFF) 1 trip indicator green)
    Mounting Support:
    lug
    [Ics] Rated Service Breaking Capacity:
    65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 5000 m with derating
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Circuit Breaker Application:
    HACR rated
    Network Frequency:
    50/60 Hz
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $5,923.00
    Add to Cart Quick view
  • Schneider Electric PGA36040U33A Molded Case Circuit Breaker 600V 400A
    Add to Cart
    Quick view

    Schneider Electric PGA36040U33A Molded Case Circuit Breaker 600V 400A

    Schneider Electric

    $15,729.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PGA36040U33A
    Circularity Profile:
    ENVEOLI2206033EN
    Terminal Identifier:
    AL800M23K
    Product Name:
    PowerPact P
    Ambient Air Temperature For Storage:
    -50-85 °C
    Quantity Per Set:
    1
    Depth:
    8.05 in
    Sustainable Offer Status:
    Green Premium product
    Width:
    8.27 in
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Eu Rohs Directive:
    Compliant with Exemptions
    Mounting Mode:
    I-Line bracket)
    Height:
    12.86 in
    Product Or Component Type:
    circuit breaker
    Trip Unit Technology:
    electronic, standard, MicroLogic 5.0, LSI
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Line Rated Current:
    400-400 A
    Mercury Free:
    Yes
    Ambient Air Temperature For Operation:
    -2-70 °C
    Ip Degree Of Protection:
    front cover IP40
    Continuous Current Rating:
    0.8
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    [Ics] Rated Service Breaking Capacity:
    25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Device Application:
    distribution
    Range:
    PowerPact
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Environmental Disclosure:
    ENVPEP2206033EN
    Control Type:
    toggle
    Trip Unit Name:
    MicroLogic 5.0
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Product Certifications:
    UL || CSA || NOM
    Rohs Exemption Information:
    Yes
    Poles Description:
    3P
    Circuit Breaker Application:
    HACR rated
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Local Signalling:
    1 trip indicator green)
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Pvc Free:
    Yes
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Wire Stripping Length:
    25 mm
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Net Weight:
    32 lb(US)
    Mounting Support:
    bracket
    Network Frequency:
    50/60 Hz
    Quality Labels:
    CE
    Warranty:
    18 months
    Phase Connection:
    ABC
    Breaking Capacity Code:
    G
    Electrical Connection:
    I-Line connection, line || lugs, load
    Pollution Degree:
    3 IEC 60947-1
    Mounting Height:
    9 in
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $15,729.00
    Add to Cart Quick view
  • Schneider Electric PGA36025U33A Molded Case Circuit Breaker 600V 250A
    Add to Cart
    Quick view

    Schneider Electric PGA36025U33A Molded Case Circuit Breaker 600V 250A

    Schneider Electric

    $15,729.00
    PowerPacT P-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT P-Frame circuit breakers have either a fixed long time electronic trip unit, ET 1.0I, or Micrologic trip units...
    SKU:
    PGA36025U33A
    Pollution Degree:
    3 IEC 60947-1
    [Uimp] Rated Impulse Withstand Voltage:
    8 kV IEC 60947-2
    Breaking Capacity:
    AIR 65 kA 240 V AC 50/60 Hz UL 489 || AIR 35 kA 480 V AC 50/60 Hz UL 489 || AIR 18 kA 600 V AC 50/60 Hz UL 489 || Icu 50 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 35 kA 380/415 V AC 50/60 Hz IEC 60947-2
    Operating Altitude:
    < 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating
    Trip Unit Name:
    MicroLogic 5.0
    Quantity Per Set:
    1
    Electrical Connection:
    I-Line connection, line || lugs, load
    Line Rated Current:
    250-250 A
    Device Application:
    distribution
    Width:
    8.27 in
    Long Time Pick-Up Adjustment Range:
    0.4...1 x Ir
    [Ics] Rated Service Breaking Capacity:
    25 kA 240 V AC 50/60 Hz IEC 60947-2 || 20 kA 380/415 V AC 50/60 Hz IEC 60947-2
    [Ui] Rated Insulation Voltage:
    750 V IEC 60947-2
    Standards:
    UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    Control Type:
    toggle
    Product Name:
    PowerPact P
    Environmental Disclosure:
    ENVPEP1407012EN
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m
    Awg Gauge:
    3 x AWG 3/0...500 kcmil aluminium/copper
    Quality Labels:
    CE
    Rohs Exemption Information:
    Yes
    Sustainable Offer Status:
    Green Premium product
    Circuit Breaker Application:
    HACR rated
    Net Weight:
    32 lb(US)
    Mounting Support:
    bracket
    Depth:
    8.05 in
    Height:
    12.86 in
    Trip Unit Technology:
    electronic, standard, MicroLogic 5.0, LSI
    Local Signalling:
    1 trip indicator green)
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Wire Stripping Length:
    25 mm
    Network Frequency:
    50/60 Hz
    Ambient Air Temperature For Operation:
    -2-70 °C
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Continuous Current Rating:
    0.8
    Mercury Free:
    Yes
    Number Of Slots:
    2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    Circularity Profile:
    ENVEOLI1407012EN
    Product Or Component Type:
    circuit breaker
    Ip Degree Of Protection:
    front cover IP40
    Eu Rohs Directive:
    Compliant
    Ambient Air Temperature For Storage:
    -50-85 °C
    Product Certifications:
    UL || CSA || NOM
    Pvc Free:
    Yes
    Range:
    PowerPact
    Warranty:
    18 months
    Phase Connection:
    ABC
    Mounting Mode:
    I-Line bracket)
    Mounting Height:
    9 in
    Poles Description:
    3P
    [Ue] Rated Operational Voltage:
    600 V AC 50/60 Hz UL 489
    Breaking Capacity Code:
    G
    Terminal Identifier:
    AL800M23K
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $15,729.00
    Add to Cart Quick view
  • Schneider Electric PJL36000S10 Automatic Molded Case Switch 600V 1000A
    Add to Cart
    Quick view

    Schneider Electric PJL36000S10 Automatic Molded Case Switch 600V 1000A

    Schneider Electric

    $9,287.00
    PowerPacT P-Frame automatic switches are a disconnect device and can be used to open and close a circuit under normal operating conditions. The automatic switches are similar in construction, use the same accessories, and offer the same connection...
    SKU:
    PJL36000S10
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Sustainable Offer Status:
    Green Premium product
    Poles Description:
    3P
    Eu Rohs Directive:
    Compliant with Exemptions
    Electrical Connection:
    lugs, line || lugs, load
    Depth:
    8.05 in
    Product Or Component Type:
    automatic switch
    Device Application:
    distribution
    Terminal Identifier:
    AL800M23K
    China Rohs Regulation:
    Product out of China RoHS scope. Substance declaration for your information.
    Environmental Disclosure:
    ENVPEP2206033EN
    Rohs Exemption Information:
    Yes
    Pvc Free:
    Yes
    Height:
    16.16 in
    Tightening Torque:
    50-50 N.m 95-240 mm² (3 x AWG 3/0...3 x 500 kcmil) || 1.0-1.3 N.m
    Circularity Profile:
    ENVEOLI2206033EN
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
    Warranty:
    18 months
    Mercury Free:
    Yes
    Width:
    8.27 in
    Breaking Capacity Code:
    J
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $9,287.00
    Add to Cart Quick view
