Contactors & Reversing Contactors
-
Schneider Electric LC2D32JL
Schneider Electric
$535.00Reversing Contactor, TeSys Deca, 3P(3NO), AC-3,- SKU:
- LC2D32JL
$535.00 -
Schneider Electric LX4D8BD
Schneider Electric
$81.90TeSys D replacement DCcoil 24V, for TeSys D contactors. To be used with 3 and 4-pole contactors LC1 D115, D150. It operates in the voltage limits 0.75-1.2 Uc. Coil with integral suppression device fitted as standard. Green Premium compliant (RoHS/REACh).- SKU:
- LX4D8BD
$81.90 -
Schneider Electric A9XPH212 Acti9 Comb Busbar 2P 100A 12 Modules
Schneider Electric
$47.02This Acti9 product is a cuttable horizontal comb busbar 12 modules for Acti9 iC60 or Acti9 iK60. It is dedicated to N+1L installations. The type is NL (Neutral, Line). It is a set of 1 device. It is suitable for 6 devices (1P+N). The length is 220mm.The...- SKU:
- A9XPH212
- [Ue] Rated Operational Voltage:
- 415 V AC
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Device Presentation:
- cuttable
- Connection Pitch:
- 18 mm
- Color:
- White RAL 9003)
- Marking:
- N L
- Range:
- Acti9
- Pollution Degree:
- 3 IEC 60947-7-1
- Insulation:
- insulated
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Lines Description:
- 1L + N
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- Warranty:
- 18 months
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- 9 Mm Pitches:
- 24
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Mercury Free:
- Yes
- Toxic Heavy Metal Free:
- Yes
- Rohs Exemption Information:
- Yes
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Total Number Of 18 Mm Modules:
- 12
- Environmental Disclosure:
- ENVPEP2005011
- Distance Between Way:
- 36 mm
- Connector Type:
- tooth
- Number Of Ways:
- 6 ways N + 1 L
- Poles Configuration For 1 Way:
- 1 x 1P + N || 1 x 2P
- Width:
- 220 mm
- Circularity Profile:
- N/A
- Sustainable Offer Status:
- Green Premium product
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Product Or Component Type:
- comb busbar
- Eu Rohs Directive:
- Compliant
- Reach Free Of Svhc:
- Yes
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Accessory / Separate Part Category:
- connection accessory
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Mounting Mode:
- horizontal
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$47.02 -
Schneider Electric A9XPH112 Acti9 Comb Busbar 1P 100A 12 Modules
Schneider Electric
$17.13This Acti9 product is a cuttable horizontal comb busbar 12 modules for Acti9 iC60 or Acti9 iK60. It is dedicated to 1L installations. The type is L (Line). It is a set of 1 device. It is suitable for 12 devices (1P). The length is 220mm.The total number...- SKU:
- A9XPH112
- Distance Between Way:
- 18 mm
- Width:
- 220 mm
- Accessory / Separate Part Category:
- connection accessory
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Number Of Ways:
- 12 ways 1 L
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Toxic Heavy Metal Free:
- Yes
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Total Number Of 18 Mm Modules:
- 12
- Warranty:
- 18 months
- Rohs Exemption Information:
- Yes
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Device Presentation:
- cuttable
- Marking:
- L
- Product Or Component Type:
- comb busbar
- Mercury Free:
- Yes
- Insulation:
- insulated
- Connector Type:
- tooth
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- Sustainable Offer Status:
- Green Premium product
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Poles Configuration For 1 Way:
- 1 x 1P
- Connection Pitch:
- 18 mm
- Circularity Profile:
- N/A
- Environmental Disclosure:
- ENVPEP2005011
- Range:
- Acti9
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Reach Free Of Svhc:
- Yes
- [Ue] Rated Operational Voltage:
- 415 V AC
- 9 Mm Pitches:
- 24
- Eu Rohs Directive:
- Compliant
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Lines Description:
- 1L
- Color:
- White RAL 9003)
- Mounting Mode:
- horizontal
- Pollution Degree:
- 3 IEC 60947-7-1
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$17.13 -
Schneider Electric A9XPH424 Acti9 Comb Busbar 4P 100A 24 Modules Pack of 5
Schneider Electric
$675.00This Acti9 product is a cuttable horizontal comb busbar 24 modules for Acti9 iC60 or Acti9 iK60. It is dedicated to N+3L installations. The type is NL1L2L3 (Neutral, Line). It is a set of 1 device. It is suitable for 6 devices (3P+N). The length is 430mm...- SKU:
- A9XPH424
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- 9 Mm Pitches:
- 48
- Connection Pitch:
- 18 mm
- [Ue] Rated Operational Voltage:
- 415 V AC
- Circularity Profile:
- N/A
- Mercury Free:
- Yes
- Total Number Of 18 Mm Modules:
- 24
- Toxic Heavy Metal Free:
- Yes
- Range:
- Acti9
- Width:
- 430 mm
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Accessory / Separate Part Category:
- connection accessory
- Product Or Component Type:
- comb busbar
- Distance Between Way:
- 72 mm
- Device Presentation:
- cuttable
- Connector Type:
- tooth
- Poles Configuration For 1 Way:
- 1 x 3P + N || 1 x 4P
- Lines Description:
- 3L + N
- Insulation:
- insulated
- Pollution Degree:
- 3 IEC 60947-7-1
- Sustainable Offer Status:
- Green Premium product
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Number Of Ways:
- 6 ways N + 3 L
- Eu Rohs Directive:
- Compliant
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Marking:
- N L1 L2 L3
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Rohs Exemption Information:
- Yes
- Color:
- White RAL 9003)
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Environmental Disclosure:
- ENVPEP2005011
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Warranty:
- 18 months
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Reach Free Of Svhc:
- Yes
- Mounting Mode:
- horizontal
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Brochure:
- View
- Datasheet:
- View
$675.00 -
Schneider Electric A9XPH224 Acti9 Comb Busbar 2P 100A 24 Modules Pack of 5
Schneider Electric
$337.50This Acti9 product is a cuttable horizontal comb busbar 24 modules for Acti9 iC60 or Acti9 iK60. It is dedicated to N+1L installations. The type is NL (Neutral, Line). It is a set of 1 device. It is suitable for 12 devices (1P+N). The length is 430mm...- SKU:
- A9XPH224
- Sustainable Offer Status:
- Green Premium product
- Accessory / Separate Part Category:
- connection accessory
- Circularity Profile:
- N/A
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Total Number Of 18 Mm Modules:
- 24
- Poles Configuration For 1 Way:
- 1 x 1P + N || 1 x 2P
- Connection Pitch:
- 18 mm
- Lines Description:
- 1L + N
- Connector Type:
- tooth
- Reach Free Of Svhc:
- Yes
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Mounting Mode:
- horizontal
- Number Of Ways:
- 12 ways N + 1 L
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Toxic Heavy Metal Free:
- Yes
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Color:
- White RAL 9003)
- Environmental Disclosure:
- ENVPEP2005011
- 9 Mm Pitches:
- 48
- Rohs Exemption Information:
- Yes
- Range:
- Acti9
- Mercury Free:
- Yes
- Marking:
- N L
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Insulation:
- insulated
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- Width:
- 430 mm
- Pollution Degree:
- 3 IEC 60947-7-1
- Distance Between Way:
- 36 mm
- Device Presentation:
- cuttable
- Warranty:
- 18 months
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- [Ue] Rated Operational Voltage:
- 415 V AC
- Eu Rohs Directive:
- Compliant
- Product Or Component Type:
- comb busbar
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$337.50 -
Schneider Electric LV432624 Platine Compact Nsx 400-630 4P
Schneider Electric
$789.75The NSX mounting plate system for busbar simplifies the installation of 4 poles NSX 400-630 circuit breaker. Power distribution is performed by a busbar. The mounting plate is fitted directly on the busbar, by snap-on-mounting. thus implementing...- SKU:
- LV432624
- Product Name:
- BZ
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Range:
- Linergy
- Sustainable Offer Status:
- Green Premium product
- Eu Rohs Directive:
- Compliant
- Product Compatibility:
- NSX400...630
- Number Of Ways:
- 1 way
- [Ui] Rated Insulation Voltage:
- 690 V
- Range Compatibility:
- Prisma G || Prisma P || Prisma PH || Spacial || ComPact
- Reach Free Of Svhc:
- Yes
- Product Or Component Type:
- adaptors for busbar systems
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Width:
- 184 mm
- Depth:
- 63 mm
- Rohs Exemption Information:
- Yes
- Poles Description:
- 4P
- Environmental Disclosure:
- ENVPEP120206EN
- Device Short Name:
- LA9Z
- Circularity Profile:
- N/A
- Permissible Current:
- 200 A 12 x 5 mm || 250 A 15 x 5 mm || 320 A 20 x 5 mm || 400 A 25 x 5 mm || 450 A 30 x 5 mm || 360 A 12 x 10 mm || 520 A 20 x 10 mm || 630 A 30 x 10 mm
- Height:
- 284 mm
- Ip Degree Of Protection:
- IP20 IEC 60529
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Toxic Heavy Metal Free:
- Yes
- Mercury Free:
- Yes
- Color:
- anthracite grey
- Datasheet:
- View
$789.75 -
Schneider Electric LV429373 Platine Compact Nsx 100-250 4P
Schneider Electric
$286.20The NSX mounting plate system for busbar simplifies the installation of 4 poles NSX 100-250 circuit breaker. Power distribution is performed by a busbar. The mounting plate is fitted directly on the busbar, by snap-on-mounting. thus implementing...- SKU:
- LV429373
- Sustainable Offer Status:
- Green Premium product
- Width:
- 139 mm
- Ip Degree Of Protection:
- IP20 IEC 60529
- Product Compatibility:
- NSX100...250
- Mercury Free:
- Yes
- Circularity Profile:
- N/A
- Reach Free Of Svhc:
- Yes
- Poles Description:
- 4P
- Height:
- 251 mm
- Product Or Component Type:
- adaptors for busbar systems
- Permissible Current:
- 200 A 12 x 5 mm || 250 A 15 x 5 mm || 250 A 20 x 5 mm || 250 A 25 x 5 mm || 250 A 30 x 5 mm || 250 A 12 x 10 mm || 250 A 20 x 10 mm || 250 A 30 x 10 mm
- Device Short Name:
- LA9Z
- Number Of Ways:
- 1 way
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Rohs Exemption Information:
- Yes
- Environmental Disclosure:
- ENVPEP120206EN
- Toxic Heavy Metal Free:
- Yes
- Eu Rohs Directive:
- Compliant
- Depth:
- 63 mm
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Range:
- Linergy
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- [Ui] Rated Insulation Voltage:
- 690 V
- Range Compatibility:
- Prisma G || Prisma P || Prisma PH || Spacial || ComPact
- Color:
- anthracite grey
- Product Name:
- BZ
- Datasheet:
- View
$286.20 -
Schneider Electric CA3KN22BD K Control Relay 2No 2Nc 24Vdc Coil
Schneider Electric
$62.75TeSys K control relay, 4 contacts (2NO + 2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 24V DC control circuit with no inrush consumption, connection by screw clamp terminals. For high operating rates until 180 cycles/min...- SKU:
- CA3KN22BD
- Insulation Resistance:
- > 10 MOhm
- Hold-In Power Consumption In W:
- 3-3 W 20 °C
- [Ue] Rated Operational Voltage:
- <= 690 V <= 400 Hz
- [Ith] Conventional Free Air Thermal Current:
- 10 A (at 50 °C)
- Range:
- TeSys
- Circularity Profile:
- ENVEOLI1503003EN
- Product Or Component Type:
- control relay
- Associated Fuse Rating:
- 10 A gG conforming to IEC 60947 || 10 A gG conforming to VDE 0660
- Eu Rohs Directive:
- Compliant
- Ip Degree Of Protection:
- IP2X
- Tightening Torque:
- 1.3 N.m screw clamp terminals flat à 6 mm || 1.3 N.m screw clamp terminals Philips No 2 6 mm
- Irms Rated Making Capacity:
- 110 A IEC 60947
- Control Circuit Voltage Limits:
- operational: 0.8...1.15 Uc (at <50 °C) || drop-out: 0.1...0.75 Uc (at <50 °C)
- Flame Retardance:
- V1 conforming to UL 94 || requirement 2 conforming to NF F 16-101 || requirement 2 conforming to NF F 16-102
- Ambient Air Temperature For Operation:
- -25-50 °C
- Standards:
- EN/IEC 60947-4-1 || GB/T 14048.4 || UL 60947-4-1 || CSA C22.2 No 60947-4-1 || JIS C8201-4-1
- Width:
- 45 mm
- Environmental Disclosure:
- ENVPEP1503003EN
- Inrush Power In W:
- 3-3 W 20 °C)
- Minimum Switching Current:
- 5 mA
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Product Name:
- TeSys CAK
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Immunity To Microbreaks:
- 2 ms
- Warranty:
- 18 months
- Connections - Terminals:
- screw clamp terminals 1 1.5-4 mm²solid || screw clamp terminals 2 1.5-4 mm²solid || screw clamp terminals 1 0.75-4 mm²flexible with cable end || screw clamp terminals 2 0.75-4 mm²flexible without cable end || screw clamp terminals 1 0.34-1.5 mm²
- Device Short Name:
- CA3K
- Net Weight:
- 0.225 kg
- Pole Contact Composition:
- 2 NO + 2 NC
- [Uc] Control Circuit Voltage:
- 24 V DC
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Rohs Exemption Information:
- Yes
- Heat Dissipation:
- 3-3 W
- Mechanical Robustness:
- vibrations contactor open2 Gn, 5...300 Hz IEC 60068-2-6 || vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 || shocks contactor open10 Gn for 11 ms IEC 60068-2-27 || shocks contactor closed15 Gn for 11 ms IEC 60068-2-27
- Contactor Application:
- control circuit
- Protective Treatment:
- TC IEC 60068
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Mercury Free:
- Yes
- Minimum Switching Voltage:
- 17 V
- Control Circuit Type:
- DC standard
- [Ui] Rated Insulation Voltage:
- 690 V IEC 60947 || 750 V VDE 0110 group C || 690 V BS 5424 || 600 V CSA C22.2 No 14
- Depth:
- 57 mm
- Reach Free Of Svhc:
- Yes
- Product Certifications:
- CB Scheme || CCC || UL || CSA || EAC || CE || UKCA
- Mechanical Durability:
- 20 Mcycles
- Non Overlap Distance:
- 0.5 mm
- Toxic Heavy Metal Free:
- Yes
- Ambient Air Temperature For Storage:
- -50-80 °C
- Height:
- 58 mm
- Utilisation Category:
- AC-15 || DC-13
- Mounting Support:
- rail || plate
- Sustainable Offer Status:
- Green Premium product
- Datasheet:
- View
$62.75 -
Schneider Electric A9XPH324 Acti9 Comb Busbar 3P 100A 24 Modules
Schneider Electric
$95.61This Acti9 product is a cuttable horizontal comb busbar 24 modules for Acti9 iC60 or Acti9 iK60. It is dedicated to 3L installations. The type is L1L2L3 (Line). It is a set of 1 device. It is suitable for 8 devices (3P). The length is 430mm.The total...- SKU:
- A9XPH324
- Marking:
- L1 L2 L3
- Distance Between Way:
- 54 mm
- Warranty:
- 18 months
- Number Of Ways:
- 8 ways 3 L
- Reach Free Of Svhc:
- Yes
- Pollution Degree:
- 3 IEC 60947-7-1
- Sustainable Offer Status:
- Green Premium product
- Connection Pitch:
- 18 mm
- 9 Mm Pitches:
- 48
- Poles Configuration For 1 Way:
- 1 x 3P
- Connector Type:
- tooth
- Mercury Free:
- Yes
- Color:
- White RAL 9003)
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- [Ue] Rated Operational Voltage:
- 415 V AC
- [Ie] Rated Operational Current:
- 100 A 40 °C
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Device Presentation:
- cuttable
- Toxic Heavy Metal Free:
- Yes
- Product Or Component Type:
- comb busbar
- Range:
- Acti9
- Environmental Disclosure:
- ENVPEP2005011
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Accessory / Separate Part Category:
- connection accessory
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Mounting Mode:
- horizontal
- Total Number Of 18 Mm Modules:
- 24
- Width:
- 430 mm
- Eu Rohs Directive:
- Compliant
- Insulation:
- insulated
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Lines Description:
- 3L
- Circularity Profile:
- N/A
- Rohs Exemption Information:
- Yes
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Brochure:
- View
- Datasheet:
- View
$95.61 -
Schneider Electric A9XPH312 Acti9 Comb Busbar 3P 100A 12 Modules
Schneider Electric
$82.08This Acti 9 accessory is solution for safe and reliable comb busbar. It is made for 1 pole and 3 poles devices, rated at 100 amperes and it has 12 modules. This product benefits from Schneider Electric expertise with more than 40 years developing modular...- SKU:
- A9XPH312
- Toxic Heavy Metal Free:
- Yes
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Device Presentation:
- cuttable
- Number Of Ways:
- 4 ways 3 L
- Color:
- White RAL 9003)
- Rohs Exemption Information:
- Yes
- Lines Description:
- 3L
- Range:
- Acti9
- Total Number Of 18 Mm Modules:
- 12
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Circularity Profile:
- N/A
- Insulation:
- insulated
- Accessory / Separate Part Category:
- connection accessory
- [Ue] Rated Operational Voltage:
- 415 V AC
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Warranty:
- 18 months
- Poles Configuration For 1 Way:
- 1 x 3P
- Product Or Component Type:
- comb busbar
- Distance Between Way:
- 54 mm
- Reach Free Of Svhc:
- Yes
- Eu Rohs Directive:
- Compliant
- Pollution Degree:
- 3 IEC 60947-7-1
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Mercury Free:
- Yes
- Connection Pitch:
- 18 mm
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Marking:
- L1 L2 L3
- 9 Mm Pitches:
- 24
- Sustainable Offer Status:
- Green Premium product
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Width:
- 220 mm
- Environmental Disclosure:
- ENVPEP2005011
- Connector Type:
- tooth
- Mounting Mode:
- horizontal
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$82.08 -
Schneider Electric A9XPH412 Acti9 Comb Busbar 4P 100A 12 Modules Pack of 5
Schneider Electric
$330.00This Acti9 product is a cuttable horizontal comb busbar 12 modules for Acti9 iC60 or Acti9 iK60. It is dedicated to N+3L installations. The type is NL1L2L3 (Neutral, Line). It is a set of 1 device. It is suitable for 3 devices (3P+N). The length is 220mm...- SKU:
- A9XPH412
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Rohs Exemption Information:
- Yes
- Marking:
- N L1 L2 L3
- Color:
- White RAL 9003)
- Eu Rohs Directive:
- Compliant
- Product Or Component Type:
- comb busbar
- Insulation:
- insulated
- Number Of Ways:
- 3 ways N + 3 L
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- Mounting Mode:
- horizontal
- Total Number Of 18 Mm Modules:
- 12
- Width:
- 220 mm
- 9 Mm Pitches:
- 24
- Range:
- Acti9
- Sustainable Offer Status:
- Green Premium product
- Circularity Profile:
- N/A
- Warranty:
- 18 months
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Toxic Heavy Metal Free:
- Yes
- Lines Description:
- 3L + N
- Distance Between Way:
- 72 mm
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Connection Pitch:
- 18 mm
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Device Presentation:
- cuttable
- Connector Type:
- tooth
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Mercury Free:
- Yes
- [Ue] Rated Operational Voltage:
- 415 V AC
- Pollution Degree:
- 3 IEC 60947-7-1
- Accessory / Separate Part Category:
- connection accessory
- Environmental Disclosure:
- ENVPEP2005011
- Reach Free Of Svhc:
- Yes
- Poles Configuration For 1 Way:
- 1 x 3P + N || 1 x 4P
- Brochure:
- View
- Datasheet:
- View
$330.00 -
Schneider Electric A9XPH457 Acti9 Comb Busbar 4P 100A 57 Modules Pack of 5
Schneider Electric
$1,710.00This Acti9 product is a cuttable horizontal comb busbar 57 modules for Acti9 iC60 or Acti9 iK60. It is dedicated to N+3L installations. The type is NL1L2L3 (Neutral, Line). It is a set of 1 device. It is suitable for 14 devices (3P+N). The length is...- SKU:
- A9XPH457
- Mercury Free:
- Yes
- Mounting Mode:
- horizontal
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Total Number Of 18 Mm Modules:
- 57
- Warranty:
- 18 months
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Connection Pitch:
- 18 mm
- 9 Mm Pitches:
- 114
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Provided Equipment:
- set of 10 end piece
- Pollution Degree:
- 3 IEC 60947-7-1
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Reach Free Of Svhc:
- Yes
- Insulation:
- insulated
- Marking:
- N L1 L2 L3
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Color:
- White RAL 9003)
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- [Ue] Rated Operational Voltage:
- 415 V AC
- Lines Description:
- 3L + N
- Accessory / Separate Part Category:
- connection accessory
- Circularity Profile:
- N/A
- Environmental Disclosure:
- ENVPEP2005011
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Eu Rohs Directive:
- Compliant
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Sustainable Offer Status:
- Green Premium product
- Number Of Ways:
- 14 ways N + 3 L
- Connector Type:
- tooth
- Width:
- 1000 mm
- Rohs Exemption Information:
- Yes
- Product Or Component Type:
- comb busbar
- Toxic Heavy Metal Free:
- Yes
- Distance Between Way:
- 72 mm
- Poles Configuration For 1 Way:
- 1 x 3P + N || 1 x 4P
- Range:
- Acti9
- Device Presentation:
- cuttable
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$1,710.00 -
Schneider Electric A9XPH306 Acti 9 Comb Busbar 3P 100A 6 Modules
Schneider Electric
$55.00Acti9 - comb busbar - 3L - 18 mm pitch - 6 modules - 100A- SKU:
- A9XPH306
- [Ue] Rated Operational Voltage:
- 415 V AC
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Distance Between Way:
- 54 mm
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- Total Number Of 18 Mm Modules:
- 6
- Eu Rohs Directive:
- Compliant
- Toxic Heavy Metal Free:
- Yes
- Marking:
- L1 L2 L3
- Rohs Exemption Information:
- Yes
- Environmental Disclosure:
- ENVPEP2005011
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Pollution Degree:
- 3 IEC 60947-7-1
- Device Presentation:
- cuttable
- 9 Mm Pitches:
- 12
- Product Or Component Type:
- comb busbar
- Mercury Free:
- Yes
- Width:
- 110 mm
- Reach Free Of Svhc:
- Yes
- Connector Type:
- tooth
- Circularity Profile:
- N/A
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Connection Pitch:
- 18 mm
- Accessory / Separate Part Category:
- connection accessory
- Lines Description:
- 3L
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Mounting Mode:
- horizontal
- Sustainable Offer Status:
- Green Premium product
- Number Of Ways:
- 2 ways 3 L
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Color:
- White RAL 9003)
- Insulation:
- insulated
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Range:
- Acti9
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Poles Configuration For 1 Way:
- 1 x 3P
- Brochure:
- View
- Datasheet:
- View
$55.00 -
Schneider Electric A9XPH357 Acti9 Comb Busbar 3P 100A 57 Modules Pack of 5
Schneider Electric
$1,230.00This Acti 9 accessory is solution for safe and reliable comb busbar. It is made for 1 pole and 3 poles devices, rated at 100 amperes and it has 57 modules. This product benefits from Schneider Electric expertise with more than 40 years developing modular...- SKU:
- A9XPH357
- Insulation:
- insulated
- Connection Pitch:
- 18 mm
- Lines Description:
- 3L
- Number Of Ways:
- 19 ways 3 L
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Poles Configuration For 1 Way:
- 1 x 3P
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Total Number Of 18 Mm Modules:
- 57
- Connector Type:
- tooth
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Distance Between Way:
- 54 mm
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Marking:
- L1 L2 L3
- Mercury Free:
- Yes
- Provided Equipment:
- set of 10 end piece
- Toxic Heavy Metal Free:
- Yes
- Range:
- Acti9
- Pollution Degree:
- 3 IEC 60947-7-1
- Environmental Disclosure:
- ENVPEP2005011
- Product Or Component Type:
- comb busbar
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Reach Free Of Svhc:
- Yes
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Sustainable Offer Status:
- Green Premium product
- Eu Rohs Directive:
- Compliant
- Warranty:
- 18 months
- Height:
- 1000 mm
- Mounting Mode:
- horizontal
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Rohs Exemption Information:
- Yes
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- Device Presentation:
- cuttable
- Color:
- White RAL 9003)
- Circularity Profile:
- N/A
- [Ue] Rated Operational Voltage:
- 415 V AC
- Accessory / Separate Part Category:
- connection accessory
- 9 Mm Pitches:
- 114
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$1,230.00 -
Schneider Electric A9XPH124 Acti9 Comb Busbar 1P 100A 24 Modules Pack of 10
Schneider Electric
$510.00This Acti9 product is a cuttable horizontal comb busbar 24 modules for Acti9 iC60 or Acti9 iK60. It is dedicated to 1L installations. The type is L (Line). It is a set of 1 device. It is suitable for 24 devices (1P). The length is 430mm.The total number...- SKU:
- A9XPH124
- Device Presentation:
- cuttable
- Eu Rohs Directive:
- Compliant
- Accessory / Separate Part Category:
- connection accessory
- Rohs Exemption Information:
- Yes
- Product Or Component Type:
- comb busbar
- Width:
- 430 mm
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- [Ue] Rated Operational Voltage:
- 415 V AC
- Mercury Free:
- Yes
- Poles Configuration For 1 Way:
- 1 x 1P
- Environmental Disclosure:
- ENVPEP2005011
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Total Number Of 18 Mm Modules:
- 24
- Range:
- Acti9
- Circularity Profile:
- N/A
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Number Of Ways:
- 24 ways 1 L
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Toxic Heavy Metal Free:
- Yes
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Color:
- White RAL 9003)
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Pollution Degree:
- 3 IEC 60947-7-1
- Insulation:
- insulated
- Reach Free Of Svhc:
- Yes
- 9 Mm Pitches:
- 48
- Sustainable Offer Status:
- Green Premium product
- Connector Type:
- tooth
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Connection Pitch:
- 18 mm
- Mounting Mode:
- horizontal
- Distance Between Way:
- 18 mm
- Warranty:
- 18 months
- Marking:
- L
- Lines Description:
- 1L
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$510.00 -
Schneider Electric A9XPH257 Acti9 Comb Busbar 2P 100A 57 Modules
Schneider Electric
$198.00This Acti9 product is a cuttable horizontal comb busbar 57 modules for Acti9 iC60 or Acti9 iK60. It is dedicated for N+L1 installations. The type is NL (Neutral, Line). It is a set of 1 device. It is suitable for 28 devices (1P+N). The length is 1000mm...- SKU:
- A9XPH257
- Width:
- 1000 mm
- Sustainable Offer Status:
- Green Premium product
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Number Of Ways:
- 28 ways N + 1 L
- Toxic Heavy Metal Free:
- Yes
- Color:
- White RAL 9003)
- Marking:
- N L
- Insulation:
- insulated
- Mercury Free:
- Yes
- Pollution Degree:
- 3 IEC 60947-7-1
- Range:
- Acti9
- Connector Type:
- tooth
- Environmental Disclosure:
- ENVPEP2005011
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- Total Number Of 18 Mm Modules:
- 57
- Device Presentation:
- cuttable
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Warranty:
- 18 months
- Poles Configuration For 1 Way:
- 1 x 1P + N || 1 x 2P
- Lines Description:
- 1L + N
- Provided Equipment:
- set of 10 end piece
- [Ie] Rated Operational Current:
- 100 A 40 °C
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Distance Between Way:
- 36 mm
- Mounting Mode:
- horizontal
- [Ue] Rated Operational Voltage:
- 415 V AC
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Rohs Exemption Information:
- Yes
- Circularity Profile:
- N/A
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- 9 Mm Pitches:
- 114
- Reach Free Of Svhc:
- Yes
- Connection Pitch:
- 18 mm
- Product Or Component Type:
- comb busbar
- Accessory / Separate Part Category:
- connection accessory
- Eu Rohs Directive:
- Compliant
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$198.00 -
Schneider Electric A9XPH157 Acti9 Comb Busbar 1P 100A 57 Modules Pack of 5
Schneider Electric
$870.00This Acti9 product is a cuttable horizontal comb busbar 57 modules for Acti9 C60. It is dedicated to 1L installations. The type is L1 (Line). It is a set of 1 device. It is suitable for 57 devices (1P). The length is 1000mm.The total number of modules of...- SKU:
- A9XPH157
- 9 Mm Pitches:
- 114
- Pollution Degree:
- 3 IEC 60947-7-1
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Reach Free Of Svhc:
- Yes
- Insulation:
- insulated
- Range Compatibility:
- Acti 9 Acti9 iC60 || Acti 9 Acti9 iK60 || Acti 9 Acti9 iID || Acti 9 Acti9 iID K || Acti 9 Acti9 iSW || Acti 9 Acti9 iSW-NA || Multi9 Multi9 C60
- Accessory / Separate Part Category:
- connection accessory
- [Ue] Rated Operational Voltage:
- 415 V AC
- Device Presentation:
- cuttable
- Mounting Location:
- top or bottom tunnel type terminals || top or bottom double terminal
- Range:
- Acti9
- Provided Equipment:
- set of 10 end piece
- Color:
- White RAL 9003)
- Distance Between Way:
- 18 mm
- [Ui] Rated Insulation Voltage:
- 500 V AC IEC 61439-2
- Circularity Profile:
- N/A
- Standards:
- IEC 60947-7-1 || IEC 61439-2
- Mounting Mode:
- horizontal
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Eu Rohs Directive:
- Compliant
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Total Number Of 18 Mm Modules:
- 57
- Rohs Exemption Information:
- Yes
- Width:
- 1000 mm
- [Ie] Rated Operational Current:
- 100 A 40 °C
- Product Or Component Type:
- comb busbar
- Warranty:
- 18 months
- Environmental Disclosure:
- ENVPEP2005011
- Mercury Free:
- Yes
- Connector Type:
- tooth
- Marking:
- L
- Connection Pitch:
- 18 mm
- Number Of Ways:
- 57 ways 1 L
- Sustainable Offer Status:
- Green Premium product
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Poles Configuration For 1 Way:
- 1 x 1P
- Toxic Heavy Metal Free:
- Yes
- Lines Description:
- 1L
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$870.00 -
Schneider Electric GV2G05 Terminal Block For Gv1 L3
Schneider Electric
$34.20TeSys GV terminal block, 3 phases, 63A/690V, to supply busbar sets GV2G. To be mounted next to the devices connected by the busbar sets, on the same DIN rail, and connected by one of the busbar outlets. It can be fitted with a current limiter GV1L3 for...- SKU:
- GV2G05
- Rohs Exemption Information:
- Yes
- Eu Rohs Directive:
- Compliant
- Ip Degree Of Protection:
- IP20 conforming to IEC 60529
- Net Weight:
- 0.115 kg
- Mercury Free:
- Yes
- Product Or Component Type:
- terminal block
- Accessory / Separate Part Category:
- connection accessory
- [Ui] Rated Insulation Voltage:
- 690 V IEC 60947-1
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- [Ie] Rated Operational Current:
- 63 A
- Range:
- Linergy
- Connections - Terminals:
- screw clamp terminals 1 solid AWG 4 || screw clamp terminals 1 1.5-16 mm² flexible with cable end || screw clamp terminals 1 1.5-16 mm² flexible without cable end || screw clamp terminals 1 1.5-25 mm² solid || screw clamp terminals 2 1.5-4 mm² fl
- China Rohs Regulation:
- X
- Poles Description:
- 3P
- Device Short Name:
- GV2G
- Reach Free Of Svhc:
- Yes
- Range Compatibility:
- TeSys GV2 || TeSys Deca || TeSys K || TeSys U
- Product Name:
- FT
- Tightening Torque:
- 1.7-1.7 N.m screw clamp terminals || 2.2-2.2 N.m connector
- Warranty:
- 18 months
- Mounting Location:
- 35 mm DIN rail
- Toxic Heavy Metal Free:
- Yes
- Brochure:
- View
- Datasheet:
- View
$34.20 -
Schneider Electric GV1G09 Terminal Block Gv2 G Busbar
Schneider Electric
$34.10TeSys GV terminal block, 3 phases, 63A/690V, to supply busbar sets GV2G. To be inserted directly on the top terminals of the devices connected by the busbar sets. Connection to the supply cable by screw connectors. Green Premium compliant (RoHS/REACh).- SKU:
- GV1G09
- Tightening Torque:
- 1.7-1.7 N.m screw clamp terminals || 2.2-2.2 N.m connector
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Eu Rohs Directive:
- Compliant
- Poles Description:
- 3P
- [Ui] Rated Insulation Voltage:
- 690 V IEC 60947-1
- Mounting Location:
- top
- Product Certifications:
- CE || UKCA
- Range:
- Linergy
- Ip Degree Of Protection:
- IP20 conforming to IEC 60529
- Reach Free Of Svhc:
- Yes
- Connections - Terminals:
- screw clamp terminals 1 solid AWG 4 || screw clamp terminals 1 1.5-16 mm² flexible with cable end || screw clamp terminals 1 1.5-16 mm² flexible without cable end || screw clamp terminals 1 1.5-25 mm² solid || screw clamp terminals 2 1.5-4 mm² fl
- Accessory / Separate Part Category:
- connection accessory
- [Ie] Rated Operational Current:
- 63 A
- Range Compatibility:
- TeSys GV2 || TeSys Deca || TeSys U || TeSys LS1
- Product Or Component Type:
- terminal block
- Device Short Name:
- GV1G
- Toxic Heavy Metal Free:
- Yes
- Mercury Free:
- Yes
- Rohs Exemption Information:
- Yes
- China Rohs Regulation:
- X
- Product Name:
- FT
- Net Weight:
- 0.04 kg
- Warranty:
- 18 months
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
$34.10
