Leuze D9-V1-G-SGSOSRBZ2 Industrial Sensor System
Leuze
$390.00
The D9-V1-G-SGSOSRBZ2 is a precision industrial sensor engineered for demanding automation applications. Featuring IP65 protection and wide operating temperature range, it delivers reliable performance in manufacturing, logistics, and process control environments.
Technical Specifications:
Protection rating: IP65 (dust-protected, water-resistant)
Operating temperature: -25...50 °C
Technical Documentation:
Complete technical specifications, dimensional drawings, wiring diagrams, and safety documentation are available on the Leuze website at https://www.leuze.com/en-us/usa/products (search model D9-V1-G-SGSOSRBZ2). CAD models in STEP and EPLAN formats available for download to streamline machine design and panel layout.
- Series:
- D9
- Type of signaling:
- Optical and acoustic
- Life expectancy:
- > 100,000 h
- Supply voltage UB:
- 24 V, AC/DC, 10 %
- Current consumption, max.:
- 194 mA
- Type of connection:
- Terminal
- Type of terminal:
- Screw terminal
- Design:
- Cubic
- Dimension (W x H x L):
- 90 mm x 194 mm x 45 mm
- Housing material:
- Plastic
- Plastic housing:
- PC
- Housing color:
- White
- Type of fastening, at system:
- Screw type / vertical
- Type of illuminant:
- LED/24V
- Lens modules:
- 3 pieces, ready-made
- Signal image:
- Continuous light
- Angle of radiation:
- 180°
- Sequence of the modules (ascending):
- Green, orange, red
- Ambient temperature, operation:
- -25 ... 50 °C
- Degree of protection:
- IP 65
- Approvals:
- c UL US
- Tone type:
- Continuous or pulse tone
- Audio frequency:
- Approx. 2500 Hz
- Sound pressure:
- 70 ... 90 dB
- Number of tones:
- 2 Piece(s)
- Customs tariff number:
- 85318070
- ECLASS 5.1.4:
- 27371230
- ECLASS 8.0:
- 27371230
- ECLASS 9.0:
- 27371230
- ECLASS 10.0:
- 27371230
- ECLASS 11.0:
- 27371230
- ECLASS 12.0:
- 27371230
- ECLASS 13.0:
- 27371230
- ECLASS 14.0:
- 27371230
- ECLASS 15.0:
- 27371230
- ETIM 5.0:
- EC001042
- ETIM 6.0:
- EC001042
- ETIM 7.0:
- EC001042
- ETIM 8.0:
- EC001042
- ETIM 9.0:
- EC001042
- ETIM 10.0:
- EC001042
- Datasheet:
- View
- Declaration of Conformity:
- View
