Datasensing AE1/AN-2A86 Sensors
Datasensing
$43.48
The Datasensing AE1/AN-2A86 Inductive Sensor is a high-performance M8 unshielded sensor designed for precise proximity detection. Featuring a nominal sensing distance of 2.5mm and an operating range of 0 to 2.02mm, this sensor is ideal for applications requiring accurate and reliable detection. It is equipped with a 5-meter PVC cable and operates on a voltage range of 10 to 30Vdc, with a no-load supply current of ? 10mA and a load current of ? 200mA. The sensor's NPN output type with NO function ensures efficient switching at a frequency of 5kHz.
Constructed with a nickel-plated brass housing and PBT active head material, the sensor is robust and durable, offering IP67 mechanical protection against dust and water ingress. It includes essential features such as short-circuit, reverse polarity, and impulsive overvoltage protection, making it suitable for demanding industrial environments. The sensor's yellow LED indicator provides a clear output state, and it comes with two M8x1 nuts for easy installation. With CE and UR approvals and compliance with IEC 60947-5-2 for EMC compatibility, this sensor is a reliable choice for various industrial applications.
- Nominal sensing distance:
- 2,5mm
- Operanting distance:
- 0 2,02mm
- Standard target:
- 8x8mm FE360
- Correction Factor:
- copper: 0,43 / aluminium: 0,51 / brass: 0,59 / stainless steel: 0,83
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M8 standard no-flush mount
- Functions:
- Proximity
- Output type:
- NPN
- Output Function:
- NO
- Switching frequency:
- 5kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Housing Material:
- Nickel-plated brass
- Connections:
- 5m PVC Cable
- Active Head Material:
- PBT
- Tightening torque:
- 3Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M8
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Supplied Accessories:
- 2 nuts M8x1
- Dimensions:
- M8 x 1 / L = 45,5mm
- Operating Temperature:
- -25°C +70°C
- Mechanical Protection:
- IP67
- User Manuals:
- View
