Datasensing AE6/AP-3AAN Sensors

The Datasensing AE6/AP-3AAN Sensors are high-performance inductive sensors designed for precision and reliability in various industrial applications. Featuring an M8 shielded, short case flush mount, these sensors offer a nominal sensing distance of 2mm and an operating distance of 0 to 1.62mm, making them ideal for detecting standard targets of 8x8mm FE360. With a robust nickel-plated brass housing and PBT active head material, they ensure durability and longevity even in challenging environments. These sensors operate with a PNP output type and NO output function, providing a switching frequency of 5kHz and an operating voltage range of 10 to 30Vdc. They are equipped with essential protective features, including short-circuit, reverse polarity, and impulsive overvoltage protection, ensuring safe and reliable operation. The sensors also boast a low no-load supply current of ? 10mA and a load current capacity of ? 200mA, with a minimal output voltage drop of ? 1.8V at 200mA. Designed to withstand harsh conditions, the AE6/AP-3AAN sensors are rated for an operating temperature range of -25°C to +70°C and offer mechanical protection with an IP67 rating. They are compliant with EMC compatibility standards IEC 60947-5-2 and are approved with CE UR II 3G Ex nA IIC T5 Gc II 3D Ex tc IIIB T90°C Dc certifications. The sensors come with a 2m PVC cable for easy installation and include two M8x1 nuts for secure mounting. With a yellow LED indicator for output state, these sensors provide clear and immediate feedback, ensuring efficient and effective operation in any industrial setting.
