Datasensing AE6/CP-2F Sensors
Datasensing
$42.91
The Datasensing AE6/CP-2F Sensors are designed for precision and reliability in industrial applications. These inductive sensors feature a compact M8 short unshielded design with a normally closed (NC) PNP output, making them ideal for proximity detection tasks. The robust metal housing ensures durability, while the 360° visible LED status indicator provides clear operational feedback. With an IP67 rating, these sensors are protected against dust and water ingress, ensuring reliable performance in harsh environments.
The AE6/CP-2F sensors offer a nominal sensing distance of 2.5mm and an operating distance range of 0 to 2.02mm, with a standard target size of 8x8mm FE360. They are equipped with advanced protection features, including short-circuit, reverse polarity, and impulsive overvoltage protection, safeguarding against electrical damages. The sensors operate efficiently within a voltage range of 10 to 30Vdc, with a low no-load supply current of ? 10mA and a load current capacity of ? 200mA.
Constructed from nickel-plated brass, these sensors are built to withstand mechanical shocks and vibrations, complying with IEC standards. The M8 plug connection and supplied M8x1 nuts facilitate easy installation, while the PBT active head material ensures long-lasting performance. Suitable for temperatures ranging from -25°C to +70°C, the AE6/CP-2F sensors are a reliable choice for various industrial applications, offering both standard and long-distance models to meet diverse operational needs.
- Nominal sensing distance:
- 2,5mm
- Operanting distance:
- 0 2,02mm
- Standard target:
- 8x8mm FE360
- Correction Factor:
- copper: 0,43 / aluminium: 0,51 / brass: 0,59 / stainless steel: 0,83
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M8 short case no-flush mount
- Functions:
- Proximity
- Output type:
- PNP
- Output Function:
- NC
- Switching frequency:
- 5kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Weight:
- 20g
- Housing Material:
- Nickel-plated brass
- Connections:
- M8 Plug
- Active Head Material:
- PBT
- Tightening torque:
- 3Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M8
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M8x1
- Mechanical Protection:
- IP67
