Datasensing AH1/CP-4F Sensors

The Datasensing AH1/CP-4F Sensors are compact inductive sensors designed for precision and reliability. With a nominal sensing distance of 4mm and an operating range of 0 to 3.24mm, these sensors are ideal for applications requiring close proximity detection. The sensor features a robust stainless steel housing with a diameter of 6.5mm and a length of 50mm, ensuring durability and resistance to harsh environments. The unshielded design allows for versatile mounting options, while the PNP output with NC function provides reliable signal output. Equipped with a 360° visible yellow LED status indicator, the sensor offers clear visibility of the output state. It operates efficiently within a voltage range of 10 to 30Vdc, with a low no-load supply current of ? 10mA and a load current capacity of ? 200mA. The sensor is protected against short circuits, reverse polarity, impulsive overvoltage, and inductive loads, ensuring long-term operational safety. The AH1/CP-4F is designed to withstand extreme conditions, with an operating temperature range of -25°C to +70°C and an IP67 protection rating, making it suitable for use in demanding industrial environments. The sensor is compliant with CE and UR approvals and meets EMC compatibility standards as per IEC 60947-5-2. Additionally, it is resistant to shocks and vibrations, adhering to IEC 60068-2-6 and IEC 60068-2-27 standards. For applications requiring ATEX models, category 3 options are available upon request. The sensor's high repeat accuracy of < 5% and low thermal drift of Sr < 10% ensure consistent performance, while the correction factors for various materials like copper, aluminum, brass, and stainless steel provide flexibility in diverse applications.
