Datasensing AK1/AN-1A86 Sensors

The Datasensing AK1/AN-1A86 Inductive Sensor is a high-performance proximity sensor designed for precision and reliability. Featuring an M18 shielded design, this sensor operates with a Normally Open (NO) NPN output and is equipped with a 5-meter axial PVC cable for flexible installation. It offers a nominal sensing distance of 5mm and an operating range of 0 to 4.05mm, making it ideal for various industrial applications. Constructed with a nickel-plated brass housing and a PBT active head, the sensor ensures durability and resistance to harsh environments. It is capable of handling a load current of up to 400mA with a minimal output voltage drop of ? 1V at 400mA. The sensor is equipped with a yellow LED indicator for output state visibility and features comprehensive protection mechanisms, including short-circuit, reverse polarity, impulsive overvoltage, and protection against inductive loads. With a switching frequency of 600Hz and a no-load supply current of ? 20mA, the AK1/AN-1A86 is designed for efficient operation. It is compliant with CE and UR approvals and meets EMC compatibility standards (IEC 60947-5-2). The sensor is also built to withstand shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards, ensuring reliable performance in demanding conditions. The sensor's mechanical protection is rated at IP67, making it suitable for use in environments with exposure to dust and water. It operates within a temperature range of -25°C to +70°C, providing versatility across different settings. Supplied with two M18x1 nuts for secure mounting, the Datasensing AK1/AN-1A86 Inductive Sensor is a robust and dependable choice for your sensing needs.
