Datasensing AK1/CN-2A Sensors

The Datasensing AK1/CN-2A Sensors are high-performance inductive sensors designed for precision and reliability in various industrial applications. Featuring an M18 unshielded design, these sensors offer a nominal sensing distance of 8mm and an operating distance of 0 to 6.48mm, making them ideal for detecting standard targets of 24x24mm FE360. With a robust nickel-plated brass housing and PBT active head material, these sensors ensure durability and longevity even in harsh environments. The AK1/CN-2A model is equipped with an NPN output type and NC output function, providing a switching frequency of 600Hz. It operates efficiently within a voltage range of 10 to 30Vdc, with a no-load supply current of ? 20mA and a load current of ? 400mA. The sensor's design includes essential protective features such as short-circuit protection, reverse polarity protection, and impulsive overvoltage protection, ensuring reliable performance and safety. This sensor is easy to install with its 2m PVC cable connection and comes with two M18x1 nuts for secure mounting. The yellow LED indicator provides a clear output state, while the sensor's IP67 mechanical protection rating guarantees resistance to dust and water ingress. Additionally, the AK1/CN-2A complies with CE and UR approvals and meets EMC compatibility standards according to IEC 60947-5-2. Ideal for applications requiring precise proximity detection, the Datasensing AK1/CN-2A Sensors offer a versatile solution with models available in standard, long-distance, and ATEX cat. 3 configurations upon request. With a thermal drift of Sr < 10% and repeat accuracy of < 5%, these sensors deliver consistent and accurate performance, making them a reliable choice for your sensing needs.
