Datasensing AK1/CP-1A Sensors
Datasensing
$43.75
The Datasensing AK1/CP-1A Sensors are high-performance inductive sensors designed for a variety of applications. With a nominal sensing distance of 5mm and an operating range of 0 to 4.05mm, these sensors are ideal for precise proximity detection. They feature a standard target size of 18x18mm FE360 and offer correction factors for different materials, including copper, aluminum, brass, and stainless steel. The sensors are equipped with a PNP output type and an NC output function, ensuring reliable performance with a switching frequency of 600Hz.
Operating within a voltage range of 10 to 30Vdc, these sensors have a no-load supply current of ? 20mA and can handle a load current of up to 400mA. They are designed with short-circuit, reverse polarity, and impulsive overvoltage protection, making them robust and durable. The sensors are housed in nickel-plated brass with a shielded mounting design, and they come with a 2m PVC cable for easy installation.
With an IP67 degree of protection, these sensors are resistant to dust and water, making them suitable for harsh environments. They are also compliant with CE and UR approvals and meet EMC compatibility standards as per IEC 60947-5-2. The sensors are supplied with two M18x1 nuts for secure mounting and are capable of operating in temperatures ranging from -25°C to +70°C. The yellow LED indicator provides a clear output state, ensuring easy monitoring and maintenance.
- Nominal sensing distance:
- 5mm
- Operanting distance:
- 0 4,05mm
- Standard target:
- 18x18mm FE360
- Correction Factor:
- copper: 0,40 / aluminium: 0,48 / brass: 0,50 / stainless steel: 0,86
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M18 standard flush mount
- Functions:
- Proximity
- Output type:
- PNP
- Output Function:
- NC
- Switching frequency:
- 600Hz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 20mA
- Load current:
- ? 400mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1V @400mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Shielded
- Weight:
- 130g
- Housing Material:
- Nickel-plated brass
- Connections:
- 2m PVC Cable
- Active Head Material:
- PBT
- Tightening torque:
- 25Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M18
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M18x1
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
- User Manuals:
- View
