Datasensing AK1/CP-4H Sensors

The Datasensing AK1/CP-4H Sensors are high-performance inductive sensors designed for a variety of applications. With a nominal sensing distance of 12mm and an operating distance of 0 to 9.7mm, these sensors are ideal for precise proximity detection. They feature a standard target size of 36x36mm FE360 and offer correction factors for different materials, including copper, aluminum, brass, and stainless steel. The sensors are equipped with a PNP output type and an NC output function, ensuring reliable performance with a switching frequency of 300Hz. These sensors operate within a voltage range of 10 to 30Vdc and have a no-load supply current of ? 20mA. They can handle a load current of up to 400mA, with a leakage current of ? 10?A and an output voltage drop of ? 1V at 400mA. The sensors are designed with short-circuit, reverse polarity, impulsive overvoltage, and inductive load protection, making them robust and durable. Constructed with nickel-plated brass housing and an active head made of PBT, the sensors are built to withstand harsh environments, with an operating temperature range of -25°C to +70°C and a degree of protection rated at IP67. They are also EMC compatible with IEC 60947-5-2 standards and can endure shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards. The sensors come with an M12 plug connection and include two M18x1 nuts for easy installation. With a compact design of M18 x 1 / L = 64mm and a weight of 55g, these sensors are easy to integrate into various systems. The yellow LED indicator provides a clear output state, and the sensors are ready for use with a time delay before availability of ? 50ms. CE and UR approved, the Datasensing AK1/CP-4H Sensors are a reliable choice for industrial applications requiring precise and dependable sensing solutions.
