Datasensing AM1/A0-4A Sensors

Datasensing
SKU:
AM1/A0-4A
$56.09
Condition:
New
Current Stock:
The Datasensing AM1/A0-4A Sensors are high-performance inductive sensors designed for a variety of applications. With a nominal sensing distance of 8mm and an operating distance of 0 to 6.48mm, these sensors are ideal for precise proximity detection. They feature a standard target size of 24x24mm FE360 and offer correction factors for different materials such as copper (0.51), aluminium (0.56), brass (0.62), and stainless steel (0.78). The sensors exhibit a thermal drift of Sr of less than 10% and a repeat accuracy of less than 5% at 24V and 23°C ±5°C. The AM1/A0-4A models are equipped with NPN/PNP output types and a normally open (NO) output function, with a switching frequency of 750Hz. They operate within a voltage range of 10 to 30Vdc, with a no-load supply current of ? 10mA and a load current range of 3 to 100mA. The sensors have a leakage current of ? 0.8mA and an output voltage drop of ? 2.8V at 100mA. They are designed with short-circuit, reverse polarity, and impulsive overvoltage protection, as well as protection against inductive loads. Constructed with a nickel-plated brass housing and a PBT active head, these sensors are robust and durable, with an IP67 degree of protection. They are suitable for operating temperatures ranging from -25°C to +70°C and are resistant to shocks and vibrations as per IEC standards. The sensors come with a 2m PVC cable connection and include two M12x1 nuts for easy mounting. CE and UR approved, the Datasensing AM1/A0-4A Sensors are reliable and efficient solutions for industrial sensing needs.
Nominal sensing distance:
8mm
Operanting distance:
0…6,48mm
Standard target:
24x24mm FE360
Correction Factor:
copper: 0,51 / aluminium: 0,56 / brass: 0,62 / stainless steel: 0,78
Thermal drift of Sr:
< 10%
Repeat Accuracy:
< 5% (UB 24V Ta=23°C ±5°C)
Hysteresis:
1 … 20%
Description:
M12 standard no-flush mount
Functions:
Proximity
Output type:
NPN/PNP
Output Function:
NO
Switching frequency:
750Hz
Operating Voltage:
10...30Vdc
No-Load supply current:
? 10mA
Load current:
3…100mA
Leakage current:
? 0,? 8mA
Output voltage drop:
? 2,8V @100mA
Max ripple content:
? 10%
LED indicators:
Yellow LED output state
Time delay before availability:
? 50ms
Short-circuit protection:
Yes
Reverse Polarity Protection:
Yes
Impulsive Overvoltage Protection:
Yes
Protection against inductive loads:
Yes
Mounting:
Unshielded
Weight:
70g
Housing Material:
Nickel-plated brass
Connections:
2m PVC Cable
Active Head Material:
PBT
Tightening torque:
10Nm
Material:
Nickel-plated brass
Diameter/Dimension:
M12
Approvals:
CE UR
EMC compatibility:
IEC 60947-5-2
Shocks and vibrations:
Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
Degree of protection:
IP67
Supplied Accessories:
2 nuts M12x1
Mechanical Protection:
IP67
