Datasensing AM6/AN-3H Sensors
Datasensing
$48.78
The Datasensing AM6/AN-3H Sensors are high-performance inductive sensors designed for precision and reliability. Featuring a compact M12 short case flush mount, these sensors offer a nominal sensing distance of 4mm and an operating distance of 0 to 3.2mm, making them ideal for various industrial applications. The sensors are equipped with a yellow LED indicator for output state, ensuring easy monitoring. With a switching frequency of 2kHz and an operating voltage range of 10 to 30Vdc, they provide efficient performance. The sensors are built with nickel-plated brass housing and PBT active head material, ensuring durability and resistance to harsh environments. They are shielded for mounting and come with short-circuit, reverse polarity, and impulsive overvoltage protection. The sensors are CE and UR approved, with EMC compatibility according to IEC 60947-5-2 standards. They are designed to withstand shocks and vibrations, with a degree of protection rated at IP67. Supplied with two M12x1 nuts, these sensors are ready for installation in demanding conditions, operating efficiently in temperatures ranging from -25°C to +70°C.
- Nominal sensing distance:
- 4mm
- Operanting distance:
- 0 3,2mm
- Standard target:
- 12x12mm FE360
- Correction Factor:
- copper: 0,33 / aluminium: 0,4 / brass: 0,5 / stainless steel: 1,05
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M12 short case flush mount
- Functions:
- Proximity
- Output type:
- NPN
- Output Function:
- NO
- Switching frequency:
- 2kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Shielded
- Weight:
- 20g
- Housing Material:
- Nickel-plated brass
- Connections:
- M12 Plug
- Active Head Material:
- PBT
- Tightening torque:
- 10Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M12
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M12x1
- Mechanical Protection:
- IP67
