Datasensing AM6/AP-2C Sensors
Datasensing
$39.36
The Datasensing AM6/AP-2C Sensors are high-performance inductive sensors designed for precision and reliability in various industrial applications. Featuring a compact M12 short unshielded design, these sensors offer a nominal sensing distance of 4mm and an operating distance of 0 to 3.2mm, making them ideal for close-range detection tasks. The sensors are equipped with a PNP output type and a normally open (NO) output function, ensuring efficient signal processing with a switching frequency of up to 2kHz.
Constructed with a durable nickel-plated brass housing and a PBT active head, the AM6/AP-2C sensors are built to withstand harsh environments, with an operating temperature range of -25°C to +70°C and a high degree of protection rated at IP67. The sensors are equipped with a 2-meter PVC cable with a 90° output for flexible installation options.
Engineered for safety and reliability, these sensors include short-circuit protection, reverse polarity protection, impulsive overvoltage protection, and protection against inductive loads. The yellow LED indicator provides a clear visual output state, while the sensors' EMC compatibility with IEC 60947-5-2 ensures minimal interference in complex systems.
With a lightweight design of 60g and supplied with two M12x1 nuts for secure mounting, the Datasensing AM6/AP-2C Sensors are an excellent choice for applications requiring precise proximity detection and robust performance.
- Nominal sensing distance:
- 4mm
- Operanting distance:
- 0 3,2mm
- Standard target:
- 12x12mm FE360
- Correction Factor:
- copper: 0,41 / aluminium: 0,47 / brass: 0,56 / stainless steel: 1,15
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M12 short case no-flush mount
- Functions:
- Proximity
- Output type:
- PNP
- Output Function:
- NO
- Switching frequency:
- 2kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Weight:
- 60g
- Housing Material:
- Nickel-plated brass
- Connections:
- 2m PVC Cable - 90° Output
- Active Head Material:
- PBT
- Tightening torque:
- 10Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M12
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M12x1
- Mechanical Protection:
- IP67
