Datasensing AM6/BN-4H Sensors
Datasensing
$53.38
The Datasensing AM6/BN-4H Sensors are designed for precision and reliability in industrial applications. These inductive sensors feature a compact M12 short unshielded design with NO+NC/NPN output, making them ideal for proximity detection tasks. With a nominal sensing distance of 8mm and an operating range of 0 to 6.48mm, they are suitable for a variety of environments. The sensors are equipped with a yellow LED indicator for output state visibility and offer robust protection features, including short-circuit, reverse polarity, and impulsive overvoltage protection. Constructed from durable nickel-plated brass with an active head made of PBT, these sensors are built to withstand harsh conditions, operating effectively in temperatures ranging from -25°C to +70°C. They are IP67 rated for mechanical protection, ensuring resistance to dust and water ingress. The AM6/BN-4H Sensors are compatible with M12 plug connections and come with two M12x1 nuts for secure mounting. With a switching frequency of 2kHz and a load current capacity of up to 200mA, these sensors deliver high performance and reliability for demanding industrial applications.
- Nominal sensing distance:
- 8mm
- Operanting distance:
- 0 6,48mm
- Standard target:
- 24x24mm FE360
- Correction Factor:
- copper: 0,41 / aluminium: 0,46 / brass: 0,52 / stainless steel: 0,71
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M12 short case no-flush mount
- Functions:
- Proximity
- Output type:
- NPN
- Output Function:
- NO + NC
- Switching frequency:
- 2kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Weight:
- 20g
- Housing Material:
- Nickel-plated brass
- Connections:
- M12 plug
- Active Head Material:
- PBT
- Tightening torque:
- 10Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M12
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M12x1
- Mechanical Protection:
- IP67
