Datasensing AM6/BP-2A Sensors

The Datasensing AM6/BP-2A Sensors are high-performance inductive sensors designed for precision and reliability. Featuring a compact M12 short unshielded design, these sensors offer both Normally Open (NO) and Normally Closed (NC) PNP output functions, making them versatile for various applications. With a nominal sensing distance of 4mm and an operating range of 0 to 3.2mm, they are ideal for detecting standard targets of 12x12mm FE360. The sensors exhibit excellent correction factors for different materials, including copper (0.41), aluminium (0.47), brass (0.56), and stainless steel (1.15), ensuring accurate detection across diverse environments. Engineered for durability, the sensors are housed in nickel-plated brass with an active head made of PBT, providing robust protection against harsh conditions. They are equipped with a 2m PVC cable for easy connectivity and feature a yellow LED indicator for output state visibility. The sensors operate efficiently within a voltage range of 10 to 30Vdc, with a low no-load supply current of ? 10mA and a load current capacity of ? 200mA. They are designed to withstand shocks and vibrations as per IEC standards and offer IP67 mechanical protection, ensuring reliable performance in demanding industrial settings. Additional features include short-circuit, reverse polarity, impulsive overvoltage, and inductive load protection, enhancing the sensor's longevity and safety. The sensors are CE and UR approved, with EMC compatibility in accordance with IEC 60947-5-2 standards. Supplied with two M12x1 nuts for secure mounting, these sensors are an excellent choice for applications requiring precise proximity detection and robust performance.
