Datasensing AM6/CN-2A Sensors
Datasensing
$37.02
The Datasensing AM6/CN-2A Sensors are designed for precision and reliability in various industrial applications. These inductive sensors feature a compact M12 short unshielded design with a 2-meter axial cable, making them ideal for tight spaces. With a nominal sensing distance of 4mm and an operating range of 0 to 3.2mm, they ensure accurate proximity detection. The sensors are equipped with an NPN output type and a normally closed (NC) output function, supporting a switching frequency of up to 2kHz.
Built to withstand challenging environments, these sensors offer robust protection features, including short-circuit, reverse polarity, and impulsive overvoltage protection. The nickel-plated brass housing and PBT active head material provide durability, while the IP67 rating ensures resistance to dust and water ingress. The sensors operate efficiently within a temperature range of -25°C to +70°C and are compatible with a wide range of materials, with specific correction factors for copper, aluminum, brass, and stainless steel.
Additional features include a yellow LED indicator for output state, a time delay before availability of ? 50ms, and a mechanical protection rating of IP67. The sensors come with two M12x1 nuts for secure mounting and are approved with CE and UR certifications, ensuring compliance with international standards. Ideal for applications requiring precise and reliable sensing, the Datasensing AM6/CN-2A Sensors are a versatile choice for modern industrial environments.
- Nominal sensing distance:
- 4mm
- Operanting distance:
- 0 3,2mm
- Standard target:
- 12x12mm FE360
- Correction Factor:
- copper: 0,41 / aluminium: 0,47 / brass: 0,56 / stainless steel: 1,15
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M12 short case no-flush mount
- Functions:
- Proximity
- Output type:
- NPN
- Output Function:
- NC
- Switching frequency:
- 2kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Weight:
- 60g
- Housing Material:
- Nickel-plated brass
- Connections:
- 2m PVC Cable
- Active Head Material:
- PBT
- Tightening torque:
- 10Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M12
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M12x1
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
- User Manuals:
- View
