Datasensing AM6/CP-1C Sensors
Datasensing
$39.36
The Datasensing AM6/CP-1C Sensors are high-performance inductive sensors designed for precision and reliability. Featuring a compact M12 short shielded design, these sensors are ideal for applications requiring proximity detection. With a nominal sensing distance of 2mm and an operating range of 0 to 1.62mm, they ensure accurate detection of standard targets measuring 12x12mm FE360. The sensors offer a PNP output type with a normally closed (NC) function, and a switching frequency of 2kHz, making them suitable for high-speed operations.
Constructed with a durable nickel-plated brass housing and a PBT active head, these sensors are built to withstand harsh environments, with an operating temperature range of -25°C to +70°C and an IP67 degree of protection. The sensors are equipped with a 2m PVC cable with a 90° output for flexible installation options. They also feature short-circuit, reverse polarity, and impulsive overvoltage protection, ensuring reliable performance and longevity.
The AM6/CP-1C Sensors are compatible with a wide range of models, including standard, short body, and long-distance variants, with options for 2 or 3 wire connections. ATEX models, category 3, are available upon request for specialized applications. The sensors are CE and UR approved, with EMC compatibility according to IEC 60947-5-2 standards, and are designed to withstand shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards. Supplied with two M12x1 nuts for secure mounting, these sensors are an excellent choice for industrial automation and control systems.
- Nominal sensing distance:
- 2mm
- Operanting distance:
- 0 1,62mm
- Standard target:
- 12x12mm FE360
- Correction Factor:
- copper: 0,22 / aluminium: 0,31 / brass: 0,41 / stainless steel: 0,77
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M12 short case flush mount
- Functions:
- Proximity
- Output type:
- PNP
- Output Function:
- NC
- Switching frequency:
- 2kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Shielded
- Weight:
- 60g
- Housing Material:
- Nickel-plated brass
- Connections:
- 2m PVC Cable - 90° Output
- Active Head Material:
- PBT
- Tightening torque:
- 10Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M12
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M12x1
- Mechanical Protection:
- IP67
