Datasensing BS2/00-0E Sensors
Datasensing
$187.99
The Datasensing BS2/00-0E Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a diffuse reflection principle with a nominal sensing distance of 100mm, these sensors are ideal for short-distance applications. The sensors offer a wide range of models, including diffuse, retro-reflective, and polarized options, ensuring versatility for various industrial needs.
Equipped with a multifunctional DECOUT® output, the sensors provide logic connection possibilities with selectable NPN/PNP and NO/NC output types. The sensitivity can be easily adjusted using a trimmer, allowing for fine-tuning to suit specific requirements. With a high switching frequency of 80Hz and a rapid response time of 6.25ms, these sensors ensure quick and accurate performance.
The BS2/00-0E Sensors are designed for durability and reliability, featuring a robust ABS housing and an IP65 degree of protection, making them suitable for harsh environments. The sensors are completely filled with resin, providing enhanced protection against shocks and vibrations as per IEC standards. The LED status indicator offers clear visibility of the output status, while the M12 plug connection ensures easy installation and maintenance.
Operating within a wide voltage range of 10
30VDC, these sensors are equipped with short-circuit and reverse polarity protection, ensuring safe and efficient operation. The sensors are also resistant to external light interference, withstanding up to 3000lux from incandescent lamps and 10000lux from other sources.
Supplied with ST01 mounting brackets and screws, the Datasensing BS2/00-0E Sensors are ready for immediate integration into your system, providing reliable and efficient sensing solutions for your industrial applications.
- Nominal sensing distance:
- 100mm
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 80Hz
- Response time:
- 6,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status)
- Time delay before availability:
- 200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Weight:
- 185g
- Housing Material:
- ABS
- Connections:
- M12 plug 90°
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-30
- Degree of protection:
- IP65
- Supplied Accessories:
- ST01 mounting brakets and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
