Datasensing BS4/00-0C Sensors
Datasensing
$158.24
The Datasensing BS4/00-0C Sensors are designed for precision and reliability in various industrial applications. These photoelectric sensors feature a diffuse reflection principle with a nominal sensing distance of 200mm, ensuring accurate detection within short ranges. The sensors are equipped with a multifunctional DECOUT® output, offering NPN/PNP and NO/NC selectable options for versatile connectivity. With a high switching frequency of 80Hz and a rapid response time of 6.25ms, they are ideal for fast-paced environments.
The BS4/00-0C Sensors boast a robust construction, with a housing made from durable ABS material and an active head crafted from PMMA. They are completely filled with resin, providing enhanced protection against environmental factors. The sensors are designed to operate efficiently within a wide voltage range of 10 to 30VDC, with a low no-load supply current of ? 25mA and a load current capacity of ?100mA.
For ease of installation, the sensors come with a standard 2m PVC cable with a 90° exit, and they include ST01 mounting brackets and screws. The LED status indicator provides clear output status visibility, while the sensitivity adjustment trimmer allows for precise calibration. With an IP65 degree of protection, these sensors are resistant to dust and water ingress, making them suitable for challenging industrial settings.
The Datasensing BS4/00-0C Sensors are CE approved and comply with EMC compatibility standards EN 60947-5-2. They are designed to withstand shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-31 standards, ensuring reliable performance in demanding conditions. Operating within a temperature range of -25°C to +70°C, these sensors are built to endure extreme temperatures without freezing, making them a dependable choice for various applications.
- Nominal sensing distance:
- 200mm
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 80Hz
- Response time:
- 6,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status)
- Time delay before availability:
- 200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Weight:
- 185g
- Housing Material:
- ABS
- Connections:
- 2m PVC cable 90°
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-31
- Degree of protection:
- IP65
- Supplied Accessories:
- ST01 mounting brakets and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
