Datasensing BS6/00-0E Sensors
Datasensing
$196.31
The Datasensing BS6/00-0E Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a diffuse reflection function with a nominal sensing distance of 400mm, these sensors are ideal for medium-distance applications up to 600mm. The sensors offer a wide range of models, including diffuse, retro-reflective, and polarized options, ensuring versatility for various industrial needs.
Equipped with a multifunctional DECOUT® output, the sensors provide logic connection possibilities with selectable NPN/PNP and NO/NC output types. The sensitivity can be easily adjusted using a trimmer, allowing for fine-tuning to suit specific requirements. With a high switching frequency of 80Hz and a rapid response time of 6.25ms, these sensors ensure quick and accurate detection.
The BS6/00-0E Sensors are designed for durability and reliability, featuring a robust ABS housing and an active head made of PMMA. They are completely filled with resin for enhanced protection and have an IP65 degree of protection, making them suitable for harsh environments. The sensors are equipped with LED status indicators for easy monitoring and offer short-circuit and reverse polarity protection for added safety.
Operating within a voltage range of 10 to 30VDC, these sensors have a low no-load supply current of ? 25mA and a load current capacity of ?100mA. They are resistant to external light interference, withstanding up to 3000lux from incandescent lamps and 10000lux from other sources. The sensors come with an M12 plug connection and are supplied with ST01 mounting brackets and screws for easy installation.
With CE approvals and EMC compatibility according to EN 60947-5-2 standards, the Datasensing BS6/00-0E Sensors are a reliable choice for various industrial applications, offering high performance and adaptability in a compact cubic design.
- Nominal sensing distance:
- 400mm
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 80Hz
- Response time:
- 6,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status)
- Time delay before availability:
- 200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Weight:
- 185g
- Housing Material:
- ABS
- Connections:
- M12 plug 90°
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-35
- Degree of protection:
- IP65
- Supplied Accessories:
- ST01 mounting brakets and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
