Datasensing BS8/00-0C Sensors
Datasensing
$187.99
The Datasensing BS8/00-0C Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a diffuse reflection principle with a long sensing distance of up to 1.6 meters, these sensors are ideal for a variety of applications. The sensors offer a multifunctional DECOUT® output with NPN/PNP and NO/NC selectable options, providing flexibility in logic connection possibilities. With a high switching frequency of 80Hz and a rapid response time of 6.25ms, they ensure quick and accurate performance.
The sensors are equipped with a sensitivity adjustment trimmer, allowing for fine-tuning to suit specific needs. They operate within a wide voltage range of 10 to 30VDC and are protected against short circuits and reverse polarity, ensuring durability and safety. The robust ABS housing and IP65 mechanical protection make them suitable for harsh environments, withstanding temperatures from -25°C to +70°C.
The BS8/00-0C Sensors come with a standard 2-meter PVC cable with a 90° exit, and an LED status indicator for easy monitoring. The compact cubic design (16x37x64mm) and lightweight construction (185g) facilitate easy installation, complemented by the included ST01 mounting brackets and screws. With CE approvals and EMC compatibility, these sensors are a reliable choice for industrial automation and control systems.
- Nominal sensing distance:
- 1,6m
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 80Hz
- Response time:
- 6,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status)
- Time delay before availability:
- 200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Weight:
- 185g
- Housing Material:
- ABS
- Connections:
- 2m PVC cable 90°
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-36
- Degree of protection:
- IP65
- Supplied Accessories:
- ST01 mounting brakets and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
