Datasensing C18P/A0-1A Sensors
Datasensing
$173.95
The Datasensing C18P/A0-1A Sensor is a high-performance capacitive sensor designed for precision and reliability in various industrial applications. Featuring a robust M18 plastic shielded housing, this sensor offers a nominal sensing distance of 3 to 8mm with minimal thermal drift of less than 20%. It operates efficiently on both DC and AC supply voltages ranging from 20 to 250Vac at 50-60Hz, ensuring high noise immunity and consistent performance.
Equipped with adjustable sensitivity, the sensor provides flexibility to meet specific application needs. Its output type is SCR with a normally open (NO) function, supporting a switching frequency of 10Hz. The sensor is designed to handle a load current of up to 500mA, with a maximum of 2.5A for 20ms, and features a low leakage current of ? 100µA.
The C18P/A0-1A sensor is built to withstand harsh environments, with an operating temperature range of -35°C to +85°C and a storage temperature range of -40°C to +85°C. It is protected against short-circuits, polarity reversal, and overvoltage, ensuring durability and longevity. The sensor is also compliant with CE and cULus approvals, and meets EMC compatibility standards IEC 60947-5-2.
For ease of installation, the sensor comes with a 2m PVC cable and includes a screwdriver and two M18 nuts. Its compact dimensions (M18 x 1 / L = 87mm) and lightweight design (150g) make it suitable for a wide range of applications. The sensor's mechanical protection is rated at IP67 and IP68, providing excellent resistance to dust and water ingress. Additionally, it features a yellow LED indicator for object detection, ensuring clear and immediate feedback during operation.
- Nominal sensing distance:
- 3 8mm
- Thermal drift of Sr:
- < 20%
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Yes
- Hysteresis:
- ? 20%
- Output type:
- SCR
- Output Function:
- NO
- Switching frequency:
- 10Hz
- Operating Voltage:
- 20...250Vac/50-60Hz
- No-Load supply current:
- ? 12mA
- Load current:
- ? 500mA
- Leakage current:
- ? 100µA
- Output voltage drop:
- ? 10VAC @ IL ?20mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow LED (object detected)
- Time delay before availability:
- ? 200ms
- Short-circuit protection:
- polarity reversal, overvoltage
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Mounting:
- Shielded
- Weight:
- 150g
- Housing Material:
- Polyester
- Connections:
- 2m PVC cable
- Active Head Material:
- Polyester
- Tightening torque:
- 2,6Nm
- Operating temperature:
- -35°C +85°C (ohne Kondensation)
- Storage temperature:
- -40°C +85°C
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67, IP68
- Supplied Accessories:
- screw driver, 2 x M18 nuts
- Operating Temperature:
- -35°C +85°C (without freeze)
- Mechanical Protection:
- IP67, IP68
