Datasensing C18P/A0-1E Sensors
Datasensing
$171.24
The Datasensing C18P/A0-1E Sensors are designed for precision and reliability in various industrial applications. These capacitive sensors feature a robust M18 plastic shielded housing, ensuring durability and protection against harsh environments. With an adjustable sensitivity range of 3 to 8mm, they offer high noise immunity and are suitable for both DC and AC supply voltages. The sensors are equipped with a NO (normally open) output function and an SCR output type, supporting a switching frequency of 10Hz.
Engineered for efficiency, the sensors have a low no-load supply current of ? 12mA and can handle a load current of up to 500mA, with a maximum of 2.5A for 20ms. They are designed to minimize energy loss with a leakage current of ? 100µA and an output voltage drop of ? 10VAC at IL ?20mA. The sensors are equipped with a yellow LED indicator for object detection and feature short-circuit, reverse polarity, and impulsive overvoltage protection for enhanced safety.
The C18P/A0-1E Sensors are easy to install with an M12 plug connection and come with supplied accessories, including a screwdriver and two M18 nuts. They are built to withstand extreme temperatures ranging from -35°C to +85°C and are compliant with CE and cULus approvals. With a high degree of mechanical protection rated at IP67 and IP68, these sensors are ideal for environments requiring robust and reliable sensing solutions.
- Nominal sensing distance:
- 3 8mm
- Thermal drift of Sr:
- < 20%
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Yes
- Hysteresis:
- ? 20%
- Output type:
- SCR
- Output Function:
- NO
- Switching frequency:
- 10Hz
- Operating Voltage:
- 20...250Vac/50-60Hz
- No-Load supply current:
- ? 12mA
- Load current:
- ? 500mA
- Leakage current:
- ? 100µA
- Output voltage drop:
- ? 10VAC @ IL ?20mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow LED (object detected)
- Time delay before availability:
- ? 200ms
- Short-circuit protection:
- polarity reversal, overvoltage
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Mounting:
- Shielded
- Weight:
- 65g
- Housing Material:
- Polyester
- Connections:
- M12 plug
- Active Head Material:
- Polyester
- Tightening torque:
- 2,6Nm
- Operating temperature:
- -35°C +85°C (ohne Kondensation)
- Storage temperature:
- -40°C +85°C
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67, IP68
- Supplied Accessories:
- screw driver, 2 x M18 nuts
- Operating Temperature:
- -35°C +85°C (without freeze)
- Mechanical Protection:
- IP67, IP68
