Datasensing C18P/BP-1A Sensors
Datasensing
$139.97
The Datasensing C18P/BP-1A Sensors are high-performance capacitive sensors designed for precise detection tasks. Featuring a nominal sensing distance of 3 to 8mm, these sensors offer adjustable sensitivity to cater to various application needs. With a robust plastic housing and shielded design, they ensure high noise immunity and reliable operation in challenging environments. The sensors operate on a DC supply voltage ranging from 10 to 40V, with a low no-load supply current of ? 12mA, making them energy-efficient.
Equipped with both Normally Open (NO) and Normally Closed (NC) output functions, the sensors provide versatile integration options. The PNP output type supports a load current of up to 200mA, with a minimal output voltage drop of ? 2.5V at full load. The sensors are designed to withstand harsh conditions, with an operating temperature range of -35°C to +85°C and a high degree of protection rated at IP67 and IP68.
The C18P/BP-1A Sensors come with a 2-meter PVC cable for easy installation and are supplied with a screwdriver and two M18 nuts for secure mounting. The yellow LED indicator provides clear object detection feedback, while the built-in short-circuit, reverse polarity, and impulsive overvoltage protection ensure long-lasting performance. With CE and cULus approvals, these sensors meet international standards for safety and reliability, making them an ideal choice for industrial automation applications.
- Nominal sensing distance:
- 3 8mm
- Thermal drift of Sr:
- < 20%
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Yes
- Hysteresis:
- ? 20%
- Output type:
- PNP
- Output Function:
- NO + NC
- Switching frequency:
- 50Hz
- Operating Voltage:
- 10...40Vdc
- No-Load supply current:
- ? 12mA
- Load current:
- ? 200mA
- Leakage current:
- ? 100µA
- Output voltage drop:
- ? 2,5V @ IL = 200mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow LED (object detected)
- Time delay before availability:
- ? 200ms
- Short-circuit protection:
- polarity reversal, overvoltage
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Mounting:
- Shielded
- Weight:
- 150g
- Housing Material:
- Polyester
- Connections:
- 2m PVC cable
- Active Head Material:
- Polyester
- Tightening torque:
- 2,6Nm
- Storage temperature:
- -40°C +85°C
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67, IP68
- Supplied Accessories:
- screw driver, 2 x M18 nuts
- Mechanical Protection:
- IP67, IP68
