Datasensing C18P/C0-1A Sensors
Datasensing
$173.95
The Datasensing C18P/C0-1A Sensors are high-performance capacitive sensors designed for precise detection in various industrial applications. Featuring a robust M18 plastic shielded housing, these sensors offer a nominal sensing distance of 3 to 8mm with minimal thermal drift, ensuring reliable performance even in challenging environments. The adjustable sensitivity allows for customization to suit specific needs, while the high noise immunity and shielded/unshielded models provide versatility in different settings.
Operating on a wide AC voltage range of 20 to 250Vac at 50-60Hz, these sensors are equipped with an SCR output type and an NC output function, supporting a switching frequency of 10Hz. The sensors are designed with safety in mind, featuring short-circuit, reverse polarity, and impulsive overvoltage protection. The yellow LED indicator provides a clear visual signal when an object is detected.
With a durable polyester housing and active head material, the sensors are built to withstand harsh conditions, offering an operating temperature range of -35°C to +85°C and a degree of protection rated at IP67 and IP68. The sensors come with a 2m PVC cable for easy installation and are supplied with a screwdriver and two M18 nuts for secure mounting. Certified with CE and cULus approvals and compliant with IEC 60947-5-2 for EMC compatibility, these sensors are a reliable choice for industrial automation and control systems.
- Nominal sensing distance:
- 3 8mm
- Thermal drift of Sr:
- < 20%
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Yes
- Hysteresis:
- ? 20%
- Output type:
- SCR
- Output Function:
- NC
- Switching frequency:
- 10Hz
- Operating Voltage:
- 20...250Vac/50-60Hz
- No-Load supply current:
- ? 12mA
- Load current:
- ? 500mA
- Leakage current:
- ? 100µA
- Output voltage drop:
- ? 10VAC @ IL ?20mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow LED (object detected)
- Time delay before availability:
- ? 200ms
- Short-circuit protection:
- polarity reversal, overvoltage
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Mounting:
- Shielded
- Weight:
- 150g
- Housing Material:
- Polyester
- Connections:
- 2m PVC cable
- Active Head Material:
- Polyester
- Tightening torque:
- 2,6Nm
- Operating temperature:
- -35°C +85°C (ohne Kondensation)
- Storage temperature:
- -40°C +85°C
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67, IP68
- Supplied Accessories:
- screw driver, 2 x M18 nuts
- Operating Temperature:
- -35°C +85°C (without freeze)
- Mechanical Protection:
- IP67, IP68
