Datasensing CD12M/0X-050A5 Sensors
Datasensing
$57.54
Connector Female M12 Axial 8 poles cable PUR 5m
- Nominal current:
- 2 A
- Led:
- no
- Wires:
- 8
- Rated impulse voltage:
- 1,5 kV
- Nominal voltage:
- Max. 30 V ac/dc
- Connections:
- With open ended wires
- Tightening torque:
- 0,6 Nm
- Fibre lengh (m):
- 5
- Head type:
- Axial
- Plug:
- M12
- Outer diameter:
- Ø 6,4 mm ± 0,2 mm
- Jacket material:
- TPU
- Wire isolation:
- PP
- Conductors section:
- 0,34 mm2 (42 x 0,10 mm2)
- Degree of protection:
- IP67
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
