Datasensing CQ55/BP-3A Sensors
Datasensing
$153.90
The Datasensing CQ55/BP-3A Sensors are high-performance capacitive sensors designed for precise detection tasks. Featuring a cubic plastic housing, these sensors offer a nominal sensing distance of 4 to 25mm with adjustable sensitivity, ensuring adaptability to various applications. The sensors operate on a DC supply voltage of 10 to 40Vdc and are equipped with a PNP output type, providing both NO and NC output functions. With a switching frequency of 50Hz and a repeat accuracy of 5%, they deliver reliable performance in dynamic environments.
The sensors are housed in a flat polycarbonate plastic casing, measuring 55x35x15mm, and are equipped with a 2m PVC cable for easy installation. They are designed to withstand harsh conditions, with an operating temperature range of -25°C to +80°C and a storage temperature range of -40°C to +85°C. The IP67 degree of protection ensures resistance to dust and water, making them suitable for industrial applications.
Additional features include short-circuit protection with auto-reset, reverse polarity protection, and impulsive overvoltage protection, enhancing the durability and safety of the sensors. The yellow LED indicator provides a clear visual signal when an object is detected. The sensors come with a screwdriver for easy mounting, and they are compatible with both shielded and unshielded installations. Certified with CE and cULus approvals, and compliant with IEC 60947-5-2 EMC standards, the Datasensing CQ55/BP-3A Sensors are a reliable choice for your sensing needs.
- Nominal sensing distance:
- 4 25mm
- Thermal drift of Sr:
- < 20%
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Yes
- Hysteresis:
- ? 20%
- Output type:
- PNP
- Output Function:
- NO + NC
- Switching frequency:
- 50Hz
- Operating Voltage:
- 10...40Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ?200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- 2,5Vmax @IL=200mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow LED (object detected)
- Time delay before availability:
- ?100ms
- Short-circuit protection:
- Yes, autoreset
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Mounting:
- Shielded/Unshielded
- Weight:
- 150g
- Housing Material:
- PC
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Storage temperature:
- -40°C +85°C
- Diameter/Dimension:
- 55x35x15mm
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Degree of protection:
- IP67
- Supplied Accessories:
- screw driver
- Mechanical Protection:
- IP67
