Datasensing CT1/CN-2A Sensors
Datasensing
$176.34
The Datasensing CT1/CN-2A Sensors are designed for precision and reliability in various industrial applications. These capacitive sensors feature a nominal sensing distance ranging from 2 to 20mm, with a thermal drift of less than 20% and a repeat accuracy of 10%. The sensitivity can be easily adjusted using the built-in trimmer, ensuring optimal performance in diverse environments.
Housed in durable nickel-plated brass, the sensors boast an IP65 protection degree, safeguarding against dust and water ingress. The axial cable exit or optional M12 plug cable exit provides flexibility in installation, while the 2m PVC cable ensures a secure connection. The sensors operate on a voltage range of 10 to 30Vdc, with a no-load supply current of ? 8mA and a load current of ? 200mA.
Equipped with NPN output type and NC output function, the sensors offer a switching frequency of 100Hz. The LED indicators, including a green LED for power and a red LED for object detection, provide clear status updates. Safety features such as short-circuit protection with autoreset, reverse polarity protection, and impulsive overvoltage protection enhance the sensor's reliability.
The CT1/CN-2A Sensors are designed to withstand harsh conditions, with an operating temperature range of -25°C to +70°C and compliance with EMC compatibility standards IEC 60947-5-2. The sensors are also approved by CE and cULus, ensuring adherence to international safety standards. Supplied with a screwdriver and two M30 nuts, these sensors are ready for immediate installation and use.
- Nominal sensing distance:
- 2 20mm
- Thermal drift of Sr:
- < 20%
- Repeat Accuracy:
- 10%
- Sensitivity adjustment:
- Yes
- Hysteresis:
- ? 20%
- Output type:
- NPN
- Output Function:
- NC
- Switching frequency:
- 100Hz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 8mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10mA
- Output voltage drop:
- 0,75/1,8V max @ IL=10/200 mA
- Max ripple content:
- ?10%
- LED indicators:
- Green LED power, red LED (object detected)
- Time delay before availability:
- ?100ms
- Short-circuit protection:
- Yes, autoreset
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Mounting:
- Unshielded
- Weight:
- 260g
- Housing Material:
- Nickel-plated brass
- Connections:
- 2m PVC cable
- Active Head Material:
- PBT
- Tightening torque:
- 50Nm
- Operating temperature:
- -25°C +70°C
- Diameter/Dimension:
- M30
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP65
- Supplied Accessories:
- screw driver, 2 x M30 nuts
- Operating Temperature:
- -25°C +70°C (without freeze)
- Mechanical Protection:
- IP65
