The Datasensing CX2E0RA/05-032VTB Sensors are advanced area sensors designed for precision and reliability. Featuring a one-cable synchronization system, these sensors boast a nominal sensing distance ranging from 0.3 to 3 meters, with a beam spacing of 5mm and a controlled height of 320mm. Equipped with 65 parallel beams and a top beam, they ensure comprehensive area coverage. The sensors operate on a voltage range of 16.8 to 30Vdc, with a switching frequency of 18.1Hz, and offer both positive and negative slope output functions.
The sensitivity can be adjusted via a teach-in by wire method, and the sensors are protected against short-circuits, reverse polarity, and impulsive overvoltage. They feature LED indicators in blue, red, and yellow for the emitter, and green, red, and yellow for the receiver, providing clear status updates. Constructed with a durable aluminium housing and PMMA active head material, these sensors are built to withstand harsh environments, with an IP67 mechanical protection rating.
The sensors are compatible with IEC 60947-5-2 standards for EMC, shocks, and vibrations, and are approved by CE and cULus. They come with an ST151 fixing kit for easy installation. With a weight of 750g and dimensions of 329x36x20mm, these sensors are compact yet robust, suitable for a wide range of industrial applications. The operating temperature ranges from -10°C to +55°C, ensuring reliable performance in various conditions.
- Nominal sensing distance:
- 0,3 3m
- Beams space:
- 5mm
- controlled height:
- 320mm
- number of rays:
- 65
- Sensitivity adjustment:
- Teach-in by wire
- Function Principle:
- emitter/receiver
- Output type:
- 0,,,10V + 4,,,20mA
- Output Function:
- positive/negative slope
- Switching frequency:
- 18,1Hz
- Operating Voltage:
- 16,8... 30Vdc
- No-Load supply current:
- ?330mA
- Load current:
- < 100mA
- Leakage current:
- ? 10µA
- Output voltage drop:
- < 1,5V @ 100mA
- Max ripple content:
- < 1,2Vpp
- LED indicators:
- Blue, red and yellow (emitter) - green, red and yellow (receiver)
- Time delay before availability:
- < 3s
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- Infrared (850nm)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 750g
- Housing Material:
- Aluminium
- Connections:
- M12 4pin + cable PVC 200mm
- Active Head Material:
- PMMA
- Storage temperature:
- - 25°C + 60° C (without freeze)
- Approvals:
- CE, cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- IEC EN 60947-5-2
- Supplied Accessories:
- ST151 fixing kit
- Dimensions:
- 329x36x20
- Operating Temperature:
- -10°C + 55° C (without freeze)
- Mechanical Protection:
- IP67
