Datasensing CX2E0RA/10-048VTB Sensors

The Datasensing CX2E0RA/10-048VTB Sensors are designed for precision and reliability in industrial applications. Featuring a nominal sensing distance of 0.3 to 6 meters, these area sensors utilize a one-cable synchronization system with a beam spacing of 10mm and a controlled height of 480mm. They are capable of detecting objects as small as Ø 10mm with 49 parallel beams, including top beams for comprehensive coverage. The sensors offer a teach-in by wire sensitivity adjustment and operate on an emitter/receiver principle, providing both positive and negative slope output functions. With an operating voltage range of 16.8 to 30Vdc, they ensure efficient performance with a no-load supply current of ?330mA and a load current of <100mA. The sensors are equipped with LED indicators in blue, red, and yellow for the emitter, and green, red, and yellow for the receiver, ensuring clear status visibility. They feature short-circuit and reverse polarity protection, as well as impulsive overvoltage protection, making them robust against electrical disturbances. Constructed with a durable aluminium housing and PMMA active head material, these sensors are built to withstand harsh environments, with an IP67 mechanical protection rating. They are compatible with IEC 60947-5-2 standards for EMC, shocks, and vibrations, and come with a ST151 fixing kit for easy installation. Operating efficiently within a temperature range of -10°C to +55°C, the Datasensing CX2E0RA/10-048VTB Sensors are an ideal choice for demanding industrial settings.
