Datasensing CX2E0RA/10-096VTB Sensors

The Datasensing CX2E0RA/10-096VTB Sensors are advanced area sensors designed for precision and reliability. Featuring a one-cable synchronization system, these sensors boast a nominal sensing distance ranging from 0.3 to 6 meters, with a beam spacing of 10mm and a controlled height of 960mm. They are capable of detecting objects as small as Ø 10mm, utilizing 97 parallel beams for comprehensive coverage. The sensors offer a teach-in by wire sensitivity adjustment, with an emitter/receiver function principle and a versatile output type of 0 to 10V and 4 to 20mA, supporting both positive and negative slopes. Operating at a switching frequency of 12.3Hz, these sensors require an operating voltage between 16.8 to 30Vdc, with a no-load supply current of ?330mA and a load current of <100mA. They feature a low output voltage drop of <1.5V at 100mA and a maximum ripple content of <1.2Vpp. The sensors are equipped with LED indicators in blue, red, and yellow for the emitter, and green, red, and yellow for the receiver, ensuring clear status visibility. Built with durability in mind, the sensors are housed in robust aluminum with an active head made of PMMA, offering mechanical protection rated at IP67. They are designed to withstand operating temperatures from -10°C to +55°C and storage temperatures from -25°C to +60°C, without freezing. The sensors include short-circuit and reverse polarity protection, as well as impulsive overvoltage protection, ensuring reliable performance in various environments. The CX2E0RA/10-096VTB Sensors come with an ST151 fixing kit for easy installation and are approved by CE and cULus, meeting EMC compatibility standards IEC 60947-5-2 and shock and vibration standards IEC EN 60947-5-2. With dimensions of 969x36x20mm and a weight of 2700g, these sensors are a robust and efficient solution for your sensing needs.
