Datasensing DGE/11-3A Sensors
Datasensing
$53.18
The Datasensing DGE/11-3A Sensors are high-performance photoelectric sensors designed for reliable and efficient operation. Featuring a compact Ø 10 mm plastic housing with a length of 41 mm, these sensors are equipped with an irreversible spring latch fixing for secure installation. The LED status indicator provides clear visibility of the sensor's operational status, while the receiver-only design ensures focused functionality. With complete protection against electrical damages and an IP67 protection degree, these sensors are built to withstand harsh environments. The nominal sensing distance is 2 meters, with a thermal drift of Sr ?10%Sr, ensuring consistent performance. Operating on a supply voltage range of 15 to 37 VDC (10 to 30 VDC for the EA version), these sensors are CE approved and offer short-circuit and reverse polarity protection. The LED infrared emission at 880nm ensures precise detection, and the sensors are equipped with impulsive overvoltage protection. The robust construction includes a PC housing, POM fixing ring, and ABS cable exit, with a 5-meter PVC cable for flexible connectivity. Designed to operate in temperatures ranging from -25°C to +70°C, these sensors are EMC compatible with EN 60947-5-3 standards and can withstand shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27. Ideal for a variety of industrial applications, the Datasensing DGE/11-3A Sensors deliver reliable performance and durability.
- Nominal sensing distance:
- 2m
- Thermal drift of Sr:
- ?10%Sr
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Notes:
- (EG=4)
- Emitter/Receiver:
- Emitter
- Optic position:
- Axial
- Operating Voltage:
- 15 37VDC
- No-Load supply current:
- ? 10mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Supply)
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 210g
- Housing Material:
- PC housing / POM fixing ring / ABS cable exit
- Connections:
- 5m PVC cable
- Active Head Material:
- PC
- Operating temperature:
- - 25°C + 70° C (without freeze)
- Diameter/Dimension:
- Ø 10mm
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-3
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
