Datasensing DGR/01-0C Sensors
Datasensing
$62.19
The Datasensing DGR/01-0C Sensors are robust photoelectric sensor receivers designed for demanding environments. With a nominal sensing distance of 75 meters and a beam angle of ±5°, these sensors are perfect for precise detection tasks. The unit features a compact design with dimensions of Ø 10mm x 41mm, making it suitable for mounting on panels in tight spaces. Constructed with durable PC/ABS housing and a polycarbonate active head, it ensures long-lasting performance even in harsh conditions, thanks to its IP68 protection rating.
Equipped with LED indicators, the DGR/01-0C provides clear status updates on alignment, operating voltage, alarm, and output state. It supports both AC and DC operating voltages and includes relay output and alarm output for versatile integration into various systems. The double timer with independent adjustments and sensitivity adjustment allows for tailored operation to meet specific application needs.
The sensor's infrared emission and high resistance to external light interference (up to 20,000 lux) ensure reliable performance in diverse lighting conditions. With approvals such as CE and EMC compatibility conforming to EN60947-5-2, the DGR/01-0C is a trusted choice for industrial applications requiring high precision and reliability. Operating efficiently in temperatures ranging from -20°C to +60°C, this sensor is engineered to withstand the rigors of challenging environments.
- Nominal sensing distance:
- 75m
- Beam angle:
- ± 5°
- Function Principle:
- Receiver
- Optic position:
- Axial
- Operating Voltage:
- from UR control unit
- Emission:
- Infrared
- Interference to external light:
- 20000 lux
- Housing Material:
- PC / ABS cable exit
- Connections:
- 15m PVC cable
- Active Head Material:
- Polycarbonate
- Diameter/Dimension:
- Ø 10mm
- Approvals:
- CE
- EMC compatibility:
- Conforming with EMC directive according with EN60947-5-2
- Degree of protection:
- IP67
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
