Datasensing DGR/DN-3AEA Sensors
Datasensing
$75.59
The Datasensing DGR/DN-3AEA Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. With a nominal sensing distance of 2 meters and a thermal drift of Sr ?10%Sr, these sensors ensure consistent performance in various environments. The receiver operates on a 10-30VDC power supply and features an NPN Don output type, with a switching frequency of 40Hz and a rapid response time of 1.25ms.
Built with robust materials, including a PC housing, POM fixing ring, and ABS cable exit, the sensor is designed to withstand harsh conditions, offering an IP67 mechanical protection rating. The device is equipped with a 5-meter PVC cable for easy installation and connectivity. It also includes essential protections such as short-circuit, reverse polarity, and impulsive overvoltage protection, ensuring durability and safety.
The sensor's optic position is axial, and it features a yellow LED indicator for output status. It is designed to handle interference from external light up to 20,000 lux, making it suitable for various industrial applications. The DGR/DN-3AEA is CE approved and complies with EMC compatibility standards EN 60947-5-3, ensuring it meets rigorous quality and safety standards. With a compact dimension of Ø 10mm and a length of 41mm, this sensor is ideal for applications requiring precise and reliable sensing capabilities.
- Nominal sensing distance:
- 2m
- Thermal drift of Sr:
- ?10%Sr
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Notes:
- (EG=4)
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN Don
- Output Function:
- Don
- Switching frequency:
- 40Hz
- Response time:
- 1,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 10mA
- Load current:
- ?30mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=30mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Output status)
- Time delay before availability:
- ? 100ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Interference to external light:
- 20.000lux
- Impulsive Overvoltage Protection:
- Yes
- Housing Material:
- PC housing / POM fixing ring / ABS cable exit
- Connections:
- 5m PVC cable
- Active Head Material:
- PC
- Contacts material:
- PC housing / POM fixing ring / ABS cable exit
- Diameter/Dimension:
- Ø 10mm
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-3
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Dimensions:
- M10x1/L=41mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
