Datasensing DGR/LN-3AEA Sensors
Datasensing
$75.59
The Datasensing DGR/LN-3AEA Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. With a nominal sensing distance of 2 meters, these sensors are equipped with an NPN Lon output type and operate within a voltage range of 10 to 30VDC. The sensors feature a robust axial optic position and are housed in durable PC material with a POM fixing ring and ABS cable exit, ensuring long-lasting performance even in challenging environments.
These sensors are engineered with a high switching frequency of 40Hz and a rapid response time of 1.25ms, making them ideal for fast-paced applications. They offer excellent protection features, including short-circuit protection, reverse polarity protection, and impulsive overvoltage protection, ensuring reliable operation. The sensors are also resistant to external light interference up to 20,000 lux and have a mechanical protection rating of IP67, making them suitable for use in harsh conditions.
The DGR/LN-3AEA Sensors come with a 5-meter PVC cable for easy installation and connectivity. They are CE approved and comply with EMC compatibility standards EN 60947-5-3. Additionally, they are designed to withstand shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards. With a compact dimension of M10x1/L=41mm and an operating temperature range of -25°C to +70°C, these sensors are versatile and reliable for various industrial applications.
- Nominal sensing distance:
- 2m
- Thermal drift of Sr:
- ?10%Sr
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Notes:
- (EG=4)
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN Lon
- Output Function:
- Lon
- Switching frequency:
- 40Hz
- Response time:
- 1,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 10mA
- Load current:
- ?30mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=30mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Output status)
- Time delay before availability:
- ? 100ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Interference to external light:
- 20.000lux
- Impulsive Overvoltage Protection:
- Yes
- Housing Material:
- PC housing / POM fixing ring / ABS cable exit
- Connections:
- 5m PVC cable
- Active Head Material:
- PC
- Contacts material:
- PC housing / POM fixing ring / ABS cable exit
- Diameter/Dimension:
- Ø 10mm
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-3
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Dimensions:
- M10x1/L=41mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
