Datasensing DM7/0N-1H Sensors

The Datasensing DM7/0N-1H Sensors are designed for precision and reliability in various industrial applications. Featuring models with diffuse reflection, polarized, and through-beam capabilities, these sensors offer versatile solutions for your sensing needs. With a nominal sensing distance of 300mm and a thermal drift of Sr at ?10% Sr, they ensure consistent performance. The sensors boast a repeat accuracy of 5% and a sensitivity adjustment via teach-in, making them adaptable to different environments. Equipped with a multifunction LED status indicator, these sensors provide clear operational feedback. The light-on/dark-on selectable outputs and NPN L/D selectable output type offer flexibility in integration. Built to withstand harsh conditions, they have an IP67 protection degree, ensuring complete protection against electrical damages, including short-circuit and reverse polarity protection. Operating within a voltage range of 10…30VDC, the sensors maintain a low no-load supply current of ?30mA and a load current of ?100mA. The robust nickel-plated brass housing and PMMA active head material ensure durability, while the M12 plug connection facilitates easy installation. With approvals from CE and cULus, these sensors meet high safety and quality standards. Ideal for environments with high external light interference, they can handle up to 3,000 lux from incandescent lamps and 10,000 lux from sunlight. The sensors are also equipped with impulsive overvoltage protection and are compatible with EMC standards EN 60947-5-2. With a compact design of M12x1/L=65.5mm and a weight of 28g, they are easy to integrate into existing systems. Supplied with M12 x 1 nuts, these sensors are ready for immediate deployment in temperatures ranging from -25°C to +70°C.
