Datasensing FAI9/BN-0A Sensors
Datasensing
$85.56
The Datasensing FAI9/BN-0A Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring an M18 axial diffuse design, these sensors offer a nominal sensing distance of 1 meter, making them ideal for long-distance diffuse reflection applications. With a robust plastic housing and a 2-meter PVC cable, they ensure durability and flexibility in various industrial environments. The sensors operate on a 10
30 VDC power supply and provide NPN NO+NC output functions, ensuring compatibility with a wide range of systems.
Equipped with LED infrared emission at 880nm, the FAI9/BN-0A sensors are capable of handling interference from external light sources up to 3000lux (incandescent lamp) and 10000lux (sunlight). They feature a high switching frequency of 250Hz and a rapid response time of 2ms, ensuring quick and accurate performance. The sensors are protected against short circuits, overvoltage, and reverse polarity, offering total protection against electrical damages.
With an IP67 protection degree, these sensors are resistant to dust and water, making them suitable for harsh industrial conditions. They are CE and cULus listed, ensuring compliance with international safety standards. The sensors come with supplied accessories, including M18 x 1 nuts, and are designed to withstand shocks and vibrations as per IEC standards. Operating efficiently in temperatures ranging from -25°C to +70°C, the Datasensing FAI9/BN-0A Sensors are a reliable choice for demanding applications.
- Nominal sensing distance:
- 1m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm
- Optic position:
- Axial
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 100g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
