Datasensing FAIC/BP-2E Sensors
Datasensing
$80.78
The Datasensing FAIC/BP-2E Sensors are advanced photoelectric sensors designed for precise detection tasks. Featuring a 90° retroreflective function, these sensors are capable of detecting transparent objects with a nominal sensing distance of 4 meters. They operate on a 10...30 VDC power supply and offer a PNP NO+NC output type, ensuring versatile application possibilities. The sensors are housed in durable plastic with an M12 connection, providing IP67 protection against dust and water ingress.
With a radial optic position and a flat surface design, these sensors are equipped with LED infrared emission at 880nm, ensuring reliable performance even in challenging lighting conditions, with resistance to external light interference up to 5000lux from incandescent lamps and 10000lux from sunlight. The sensors boast a high switching frequency of 250Hz and a rapid response time of 2ms, making them suitable for fast-paced environments.
Engineered for durability, the FAIC/BP-2E sensors include short-circuit and overvoltage protection, as well as reverse polarity protection, ensuring longevity and reliability. They are CE and cULus approved, meeting stringent safety and performance standards. The sensors are compact, with dimensions of M18 x 1/L=92.7mm, and lightweight at just 30g, making them easy to integrate into various systems.
Ideal for industrial applications, these sensors come with supplied accessories, including M18 x 1 nuts, and are designed to withstand operating temperatures ranging from -25°C to +70°C without freezing. The FAIC/BP-2E sensors are a robust and efficient solution for your photoelectric sensing needs.
- Nominal sensing distance:
- 4m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Retroreflective
- Notes:
- On RL110 reflector
- Optic position:
- Radial 90°
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
