Datasensing FAID/BN-2A Sensors
Datasensing
$95.97
The Datasensing FAID/BN-2A Sensors are advanced photoelectric sensors designed for precise and reliable object detection. Featuring a 90° radial optic receiver, these sensors offer a nominal sensing distance of 15 meters with adjustable sensitivity via a trimmer. They operate on a 10...30 VDC power supply and provide NPN NO+NC output functions, ensuring versatile application compatibility. The sensors boast a high switching frequency of 250Hz and a rapid response time of 2ms, making them ideal for fast-paced environments.
Constructed with a durable PBT/PC housing and a 2-meter PVC cable, the FAID/BN-2A Sensors are built to withstand harsh conditions, with an IP67 protection rating against dust and water ingress. They are equipped with LED indicators for easy status monitoring and feature comprehensive protection mechanisms, including short-circuit, overvoltage, and reverse polarity protection.
These sensors are designed to handle extreme temperatures ranging from -25°C to +70°C without freezing, and they maintain high performance even under strong external light interference. With approvals from CE and cULus, the FAID/BN-2A Sensors meet rigorous safety and quality standards, making them a reliable choice for industrial automation and control applications. Supplied with M18 x 1 nuts and a screwdriver, they are easy to install and integrate into existing systems.
- Nominal sensing distance:
- 15m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Radial 90°
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 50g
- Housing Material:
- PBT/ PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
