Datasensing FALD/BN-0E Sensors
Datasensing
$88.43
The Datasensing FALD/BN-0E Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring an axial laser receiver with a nominal sensing distance of 50 meters, these sensors are equipped with NPN NO+NC output types and offer a sensitivity adjustment via a trimmer. The robust design includes a plastic housing with IP67 protection, ensuring durability in various environments. With a switching frequency of 1kHz and a response time of 500µs, these sensors provide fast and accurate detection. They operate on a 10
30VDC power supply and are protected against short circuits, overvoltage, and reverse polarity. The sensors are compatible with M12 connections and come with supplied accessories such as M18 x 1 nuts and a screwdriver. Ideal for industrial applications, the FALD/BN-0E Sensors are CE and cULus listed, ensuring compliance with international standards.
- Nominal sensing distance:
- 50m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- Glass / PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 15°C + 55° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 15°C...+ 55°C (Without freeze)
- Mechanical Protection:
- IP67
