Datasensing FALN/BN-2A Sensors
Datasensing
$291.87
The Datasensing FALN/BN-2A Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a 90° laser retroreflective polarized design, these sensors offer a nominal sensing distance of 20 meters, with sensitivity adjustment through a convenient teach-in function. The sensors operate on a 10...30 VDC power supply and are equipped with NPN NO+NC output types, ensuring versatile application possibilities. With a robust IP67 protection rating, these sensors are built to withstand harsh environments, offering total protection against electric damages, including short-circuit and reverse polarity protection. The visible red laser emission models provide clear and accurate detection, while the radial optic position enhances performance. The sensors are housed in durable plastic with a 2-meter axial cable, and they come with essential accessories like M18 nuts and a screwdriver for easy installation. Approved by CE and cULus, these sensors are ideal for industrial applications requiring high repeat accuracy and reliable performance.
- Nominal sensing distance:
- 20m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Teach-in
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Radial 90°
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 800Hz
- Response time:
- 625µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green power supply/yellow (LightON EG?2)/yellow flashing (LightON 1
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LASER Red (650nm) class1
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 50g
- Housing Material:
- PBT/ PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- Glass / PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 15°C + 55° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 15°C...+ 55°C (Without freeze)
- Mechanical Protection:
- IP67
