Datasensing FALN/BN-2E Sensors
Datasensing
$289.21
The Datasensing FALN/BN-2E Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a 90° laser retroreflective polarized function, these sensors offer a nominal sensing distance of 20 meters with adjustable sensitivity through a convenient teach-in method. The sensors operate on a 10...30 VDC power supply and are equipped with NPN NO+NC output types, ensuring versatile application possibilities.
Constructed with a robust PBT/PC housing and an active head made of glass/PC, these sensors are built to withstand harsh environments, boasting an IP67 protection degree. The sensors are designed to resist electric damages, with comprehensive protection against short circuits, overvoltage, and reverse polarity. They are also CE and cULus approved, ensuring compliance with international standards.
The FALN/BN-2E Sensors feature a visible red laser emission for easy alignment and a radial optic position at 90°. With a high switching frequency of 800Hz and a rapid response time of 625µs, these sensors are ideal for fast-paced industrial applications. The sensors are equipped with LED indicators for power supply and operational status, providing clear visual feedback.
Additional features include a thermal drift of ?10% Sr, repeat accuracy of 5%, and a maximum ripple content of ?10%. The sensors are designed to operate efficiently in temperatures ranging from -15°C to +55°C, making them suitable for a wide range of environments. Supplied with M18 x 1 nuts and a screwdriver, the Datasensing FALN/BN-2E Sensors are ready for immediate installation and use.
- Nominal sensing distance:
- 20m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Teach-in
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Radial 90°
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 800Hz
- Response time:
- 625µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green power supply/yellow (LightON EG?2)/yellow flashing (LightON 1
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LASER Red (650nm) class1
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- Glass / PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 15°C + 55° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 15°C...+ 55°C (Without freeze)
- Mechanical Protection:
- IP67
