Datasensing FAR2/BN-2E Sensors
Datasensing
$79.97
The Datasensing FAR2/BN-2E Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a 90° diffuse reflection function, these sensors are ideal for short-distance applications up to 100mm, with a nominal sensing distance of 100mm. The sensors operate on a 10...30 VDC power supply and are equipped with NPN NO+NC output types, ensuring versatile integration into various systems.
Constructed with a robust PBT/PC housing and a PC active head, the FAR2/BN-2E sensors are built to withstand harsh environments, offering IP67 protection against dust and water ingress. The sensors are designed with a radial optic position and a red LED emission at 660nm, providing reliable performance even in challenging lighting conditions, with interference resistance up to 5000lux for incandescent lamps and 10000lux for sunlight.
With a high switching frequency of 250Hz and a rapid response time of 2ms, these sensors ensure quick and accurate detection. The sensors also feature comprehensive protection mechanisms, including short-circuit protection with autoreset, overvoltage, reverse polarity protection, and EMC compatibility according to EN 60947-5-2 standards.
The compact design, with dimensions of M18 x 1/L=92.7mm and a weight of just 30g, allows for easy installation in tight spaces. The sensors come with an M12 plug connection and are supplied with M18 x 1 nuts for secure mounting. Operating efficiently in temperatures ranging from -25°C to +70°C, the FAR2/BN-2E sensors are suitable for a wide range of industrial applications, ensuring reliable performance and longevity.
- Nominal sensing distance:
- 100mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Radial 90°
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
