The Datasensing FARL/BP-3A Sensors are designed for precision and reliability in detecting transparent objects. Featuring a photoelectric sensor with a 90° retroreflective design, these sensors offer a nominal sensing distance of 1.5 meters and a minimum sensing distance of 0.1 meters. The robust construction includes a nickel-plated brass housing with a PC cable exit, ensuring durability and protection against electric damages. With an IP67 protection degree, these sensors are suitable for harsh environments, operating efficiently within a temperature range of -25°C to +70°C.
Equipped with a PNP NO+NC output type, the FARL/BP-3A Sensors provide flexibility with both normally open and normally closed functions. The sensitivity can be easily adjusted using a trimmer, allowing for precise detection tailored to specific applications. The sensors operate on a 10
30VDC power supply, with a low no-load supply current of ?30mA and a load current of ?100mA. They feature a high switching frequency of 250Hz and a rapid response time of 2ms, making them ideal for fast-paced industrial settings.
The sensors are designed to withstand external light interference up to 5000lux from incandescent lamps and 10000lux from sunlight, ensuring reliable performance in various lighting conditions. Additional features include short-circuit protection with autoreset, overvoltage protection, and reverse polarity protection, enhancing the safety and longevity of the sensors. The package includes M18 x 1 nuts and a screwdriver for easy installation. With CE and cULus approvals, the Datasensing FARL/BP-3A Sensors meet international standards for quality and safety.
- Nominal sensing distance:
- 1,5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Minimum sensing distance (blind zone):
- 0,1m
- Function Principle:
- Transparent object
- Notes:
- On RL113G or RL116 reflector
- Optic position:
- Radial 90°
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 130g
- Housing Material:
- Nickel plated brass / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
