The Datasensing FARN/BP-1A Sensors are advanced photoelectric sensors designed for precise and reliable object detection. Featuring an axial polarized design, these sensors offer a nominal sensing distance of 4 meters and are equipped with a PNP NO+NC output type. The sensors are housed in durable nickel-plated brass with a PC cable exit, ensuring robust performance in various industrial environments. With a sensitivity adjustment trimmer, users can easily fine-tune the sensor's performance to suit specific applications. The sensors operate on a 10
30VDC power supply and are protected against short circuits, overvoltage, and reverse polarity, ensuring long-lasting reliability. The FARN/BP-1A Sensors are CE and cULus listed, with an IP67 protection degree, making them suitable for use in harsh conditions. They come with a 2-meter PVC cable for easy installation and are compatible with RL110 reflectors for enhanced detection of transparent objects. The sensors also feature LED indicators for output status and are designed to withstand shocks and vibrations, meeting IEC standards. Ideal for applications requiring high precision and durability, the Datasensing FARN/BP-1A Sensors are a versatile choice for modern industrial automation.
- Nominal sensing distance:
- 4m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 130g
- Housing Material:
- Nickel plated brass / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
