Datasensing FARP/BP-1A Sensors
Datasensing
$86.07
The Datasensing FARP/BP-1A Sensors are advanced photoelectric sensors designed for precise and reliable object detection. Featuring an axial polarized optic with a nominal sensing distance of 4 meters, these sensors are ideal for applications requiring high accuracy and stability. The robust design includes a nickel-plated brass housing with a PMMA active head, ensuring durability and resistance to harsh environments. With a power supply range of 10 to 30 VDC, the sensors offer a PNP NO+NC output type, providing flexibility in various industrial settings.
Equipped with a retro-reflective model for transparent object detection, the FARP/BP-1A Sensors utilize a red LED emission at 660nm, ensuring effective performance even in challenging lighting conditions. The sensors boast a high switching frequency of 250Hz and a rapid response time of 2ms, making them suitable for fast-paced operations. The IP67 protection degree guarantees total protection against dust and water ingress, while the short-circuit and overvoltage protection features enhance operational safety.
The sensors are designed with a 2-meter PVC cable for easy installation and connectivity. They are CE and cULus listed, ensuring compliance with international safety standards. With a compact M18 x 1/L=67.5mm dimension and a weight of 130g, the FARP/BP-1A Sensors are easy to integrate into existing systems. The operating temperature range of -25°C to +70°C allows for reliable performance in various environmental conditions. Whether for industrial automation or complex detection tasks, the Datasensing FARP/BP-1A Sensors deliver exceptional performance and reliability.
- Nominal sensing distance:
- 4m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 130g
- Housing Material:
- Nickel plated brass / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
