The Datasensing FARP/BP-2E Sensors are advanced photoelectric sensors designed for precise detection tasks. Featuring a 90° polarized optic with a nominal sensing distance of 2.5 meters, these sensors are ideal for applications requiring high accuracy and reliability. The sensors operate on a 10...30 VDC power supply and offer both axial and radial optic options with a flat surface for versatile installation. They are equipped with retro-reflective models specifically for transparent object detection, utilizing a red LED emission and boasting an IP67 protection degree for robust performance in challenging environments.
Constructed with either metallic or plastic housing, the FARP/BP-2E Sensors ensure durability and longevity. They include total protection against electric damages, with approvals from CE and cULus, ensuring compliance with international standards. The sensors feature a PNP NO+NC output type, with a switching frequency of 250Hz and a rapid response time of 2ms, making them suitable for fast-paced industrial settings.
Additional features include short-circuit and overvoltage protection, reverse polarity protection, and a high resistance to external light interference, withstanding up to 5000 lux from incandescent lamps and 10000 lux from sunlight. The sensors are compact, with dimensions of M18 x 1/L=92.7mm, and lightweight at 30g, facilitating easy integration into existing systems. They are designed to operate efficiently within a temperature range of -25°C to +70°C, without freezing, and come with supplied accessories such as M18 x 1 nuts for secure mounting.
- Nominal sensing distance:
- 2,5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Radial 90°
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
