Datasensing FFI7/BP-1EV5 Sensors

The Datasensing FFI7/BP-1EV5 Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring an M18 axial diffuse reflection design, these sensors offer a nominal sensing distance of 400mm, adjustable via a convenient teach-in sensitivity adjustment. With a repeat accuracy of 5% and a thermal drift of Sr at 10%, they ensure consistent performance even in varying conditions. The sensors operate on a PNP NO+NC output type, with a switching frequency of 500Hz and a rapid response time of 1ms, making them ideal for high-speed applications. Constructed with a robust stainless steel AISI 316L housing and PA12 plug, these sensors are built to withstand harsh environments, boasting an IP68 and IP69K mechanical protection rating. They are equipped with LED indicators for green stability and yellow output state, ensuring easy monitoring of sensor status. The sensors are protected against short-circuits and reverse polarity, and they feature a low no-load supply current of ? 35mA and a load current of ?100mA. Designed to operate efficiently within a voltage range of 10…30VDC, the FFI7/BP-1EV5 Sensors are compatible with a wide range of industrial applications. They are approved by CE, cULus, and ECOLAB Diversey, and meet EMC compatibility standards EN 60947-5-2. With a compact dimension of Ø 17.5mm and a length of 83mm, these sensors are easy to integrate into existing systems. Suitable for use in temperatures ranging from -25°C to +80°C, they are perfect for diverse environments without the risk of freezing.
